Ice-O-Matic CIM2046HR 48 1/4" Elevation Series™ Half Cube Ice Machine Head - 1830 lb/24 hr, Remote Cooled, 208-230v/1ph

Provided ideal operating conditions are met, the Ice-O-Matic CIM2046HR ice machine can produce as much as 1,830 pounds of ice a day. It’s a great option for drinking establishments and fast casual restaurants, as its half-cube ice is excellent for quickly chilling soft drinks. Its remote condenser relocates noise from the ice maker’s area to an external location to improve ambient noise levels.

Reducing potential exhaust obstruction, the Ice-O-Matic CIM2046HR ice maker is built with a dual exhaust system that expels heated air through both top and side vents. To improve ice quality, it’s built with antimicrobial defense that decreases contaminant buildup. For optimal cleaning, food zone components can be put through a commercial dishwasher.

Product Details

• Part of the Elevation Series™
• Replaces ICE1806HR and ICE2106HR
• 1,830-lb. maximum daily ice production
• 1,580-lb. daily ice production at 90 degrees F air and 70 degrees F water
• Air-cooled system with remote condenser
• Produces half-cube ice
• Half-cube size: ³⁄₈ in. x ⁷⁄₈ in. x ⁷⁄₈ in.
• Compact design saves space in tight areas
• Dual exhaust system splits airflow to reduce blockage
• LED status display
• PURE ICE® antimicrobial defense
• 1-touch descaling/sanitization
• Food zone components are dishwasher safe
• Harvest Assist
• Ideal ambient air temperature: 50-100 degrees F
• Ideal incoming water temperature: 40-100 degrees F
• Ideal incoming water pressure: 20-60 PSI
• 27,500-BTU heat transfer capacity

Product Features

Dimensions & Utilities

• Ice Maker: 48¹/₄ in. W x 24¹/₄ in. D x 26⁴/₅ in. H
• 25.6 A, 4.31 kW
• 208-230 V/60 Hz/1 ph

*Free shipping on Ice-O-Matic CIM2046HR within the 48 contiguous states.

From The Manufacturer

Elevation Series™ Modular Cube Ice Maker, air-cooled, remote condenser, dual exhaust top/side discharge, 48"W, remote cooled, approximately 1830 lb production/24 hours at 70°/50° (1580 lb at 90°70°), half size cube, PURE ICE® built in antimicrobial protection, LED status display, one touch sanitize/descaling controls, dishwasher safe food zone components, cULus, NSF, CE (Replaces ICE1806HR / ICE2106HR)

*Image may not depict product color, inclusions or accessories.

3-year Parts & Labor; 5-year Evaporator & Compressor Parts

Ice-O-Matic CIM2046HR Specifications

Documents

Spec Sheet

Warranty

Manual

Brochure
