Hatco S-9 Imperial Booster Water Heater, 16 Gallon, 9 kW, 480v/3ph
Typically ships in 3 - 4 weeks
Retail Price: $6,671.00
$3,669.05 /Each
Selected Voltage: 480V, 3 Phase
| 480V, 3 Phase |
| 208V, 1 Phase |
| 208V, 3 Phase |
| 240V, 1 Phase |
| 240V, 3 Phase |
Hatco S-9 Description
The Hatco S-9 Imperial booster heater has a large tank that can hold 16 gallons of water. This tank is surrounded by heat-retaining fiberglass insulation on the outside and coated with corrosion-resistant Castone&Reg; on the inside. Metal-sheathed heating elements run through the tank, directly heating the water, and for quick response times, the immersed thermostat quickly registers temperature changes. If the temperature gets too high or the water gets too low, the elements stop heating, preventing permanent damage to the interior.
This Hatco S-9 water booster heater is designed to bring water to 180 degrees Fahrenheit, the temperature where bacteria begins to die off. However, to accommodate low-temperature machines, its thermostat can be lowered to 140 degrees. It can warm 90 gallons of water at a 40-degree rise or 52 gallons of water at a 70-degree rise. Its pressure and temperature relief valve and pressure reduction valve help ensure it operates properly, reducing the risk of user injury.
- Maximum 90 GPH at 40-degree-F rise
- Maximum 52 GPH at 70-degree-F rise
- Accommodates high-temperature and low-temperature warewashers
- Thermostat has a high-temperature limit switch that helps prevent overheating
- 2 temperature and pressure gauges
- Pilot light
- On/off switch
- 16-gal. tank with immersed elements
- Elements deactivate if the water level is too low
- Nontoxic Castone® tank lining for corrosion protection
- Fiberglass insulation improves tank's heat retention
- Pressure reduction valve
- Pressure and temperature relief valve
- 28 53⁄100 in. W x 22 3⁄4 in. D x 31 3⁄100 in. H
- 16.3 A, 9 kW
- 480 V/60 Hz/3 ph
*Image may not depict product color, inclusions or accessories.
*Free shipping on Hatco S-9 within the 48 contiguous states.
From The Manufacturer
Hatco S-9 Specifications
| Spec Attribute | Spec Value |
|---|---|
| Manufacturer | Hatco |
| 40F Recovery (gph) | 90 |
| 70F Recovery (gph) | 52 |
| Amps | 16.3 |
| Capacity (gallons) | 16 |
| Heat | Electric |
| Hertz | 60 |
| kW | 9 |
| Phase | 3 |
| Product | Booster Heaters |
| Product Type | Dishwashing Equipment & Supplies |
| Series | Imperial |
| Usage Level | Heavy Duty |
| Voltage | 480 |
| Warranty | 1-year Parts & Labor; 10-year Tank Parts |
| Watts | 0 - 10 |
| Width (in) | 23.5 |
| Weight | 200.00 |
Important Prop 65 information for California residents.
Compare to Similar Items
| Attributes |
Hatco S-9 Hatco S-9 Imperial Booster Water Heater, 16 Gallon, 9 kW, 480v/3ph Current Item |
|||
|---|---|---|---|---|
| Customer Rating |
|
|
|
|
| Price | $3,669.05 / Each | $3,669.05 / Each | $3,669.05 / Each | $3,669.05 / Each |
| Shipping | Free Shipping | Free Shipping | Free Shipping | Free Shipping |
| Lead Time | Typically ships in 3 - 4 weeks | |||
| Usage Level | Heavy Duty | Heavy Duty | Heavy Duty | Heavy Duty |
| 40F Recovery (gph) | 90 | 90 | 90 | 90 |
| 70F Recovery (gph) | 52 | 52 | 52 | 52 |
| Capacity (gallons) | 16 | 16 | 16 | 16 |
| Width (in) | 23.5 | 23.5 | 23.5 | 23.5 |
| Watts | 0 - 10 | 0 - 10 | 0 - 10 | 0 - 10 |
| Heat | Electric | Electric | Electric | Electric |
| Voltage | 480 | 240 | 208 | 240 |
| Warranty | 1-year Parts & Labor; 10-year Tank Parts | 1-year Parts & Labor; 10-year Tank Parts | 1-year Parts & Labor; 10-year Tank Parts | 1-year Parts & Labor; 10-year Tank Parts |
