Hatco C-7 Compact Booster Water Heater, 6 Gallon, 7 kW, 480v/3ph
Estimated Backorder Until 4/21/2025
Retail Price: $4,366.00
$2,401.30 /Each
Selected Voltage: 480V, 3 Phase
| 208V, 1 Phase |
| 208V, 3 Phase |
| 240V, 1 Phase |
| 240V, 3 Phase |
| 480V, 3 Phase |
Ship times may vary due to supply chain constraints. Please contact our Sales Team if you need this item in a specified time frame.
White Glove Delivery
Contact your sales rep for availability
Similar Products in Stock Now
Hatco C-7 Description
To ensure efficient operation, the Hatco C-7 compact booster water heater comes equipped with a pilot indicator light, and while running, it automatically maintains safe internal levels using a temperature relief valve and a pressure reducing valve. Providing water temperatures of 180 degrees Fahrenheit for required sanitation, this unit's interior temperature can be monitored with two gauges. This booster can be installed with either the included 6-inch legs or with slide mounting brackets, which must be bought separately.
The Hatco C-7 compact booster water heater includes a swing-away stainless steel front panel for quick access to the probes and elements for servicing. For durability, the body is constructed of hammertone with a silver powder-coated finish, and the water tank is lined in limestone-resistant Castone®. The low-water cut-off feature and the high-temperature limit control ensure safe operation of this unit. To minimize heat loss, the tank is insulated with a layer of fiberglass.
Product Details
- Tank water reaches 180 degrees F for sanitization
- Maximum 70 GPH at 40-degree-F rise
- Maximum 40 GPH at 70-degree-F rise
- 6-gal. storage capacity
- 6-in. plastic legs
- Mountable with slide brackets (not included)
- Heat-trapping fiberglass insulation
- Powder-coated silver hammertone body
- Castone-lined tank reduces how much limestone sticks to the sides
- Stainless steel swing-away front panel enables maintenance access to probes and elements
- Pilot indicator light
- Temperature relief valve and pressure reducing valve maintain the correct level
- 2 pressure gauges
- High-temperature limit control
- Low-water cut-off protects elements from overworking and burning out
- On/off switch
- 3⁄4-in. NPT pipe
- Fittings for water inlet and outlet
Dimensions & Utilities
- 13.06 in. W x 26 in. D x 19.78 in. H
- 12.6 A, 7 kW
- 480 V/60 Hz/3 ph
*Free shipping on Hatco C-7 within the 48 contiguous states.
From The Manufacturer
Compact Booster Heater, electric, 6-gallon storage capacity, electric operation, 7-KW, stainless steel front panel, powder-coated silver-gray hammertone body, 6" plastic non-adjustable legs, Castone tank, NSF, cUL, UL, 480v/60/3ph
*Image may not depict product color, inclusions or accessories.
Hatco C-7 Specifications
| Spec Attribute | Spec Value |
|---|---|
| Manufacturer | Hatco |
| 40F Recovery (gph) | 70 |
| 70F Recovery (gph) | 40 |
| Amps | 12.6 |
| Capacity (gallons) | 6 |
| Heat | Electric |
| Hertz | 60 |
| kW | 7 |
| Phase | 3 |
| Product | Booster Heaters |
| Product Type | Dishwashing Equipment & Supplies |
| Usage Level | Medium Duty |
| Voltage | 480 |
| Warranty | 1-year Parts & Labor; 10-year Tank Parts |
| Watts | 0 - 10 |
| Width (in) | 13 |
| Weight | 118.00 |
