True TCIM-522-HA1-A/TIB-422-A 550 lb True Ice Series Half Cube Ice Machine w/ Bin - 320 lb Storage, Air Cooled, 115v
QUICK SHIP: Typically ships in 1 - 3 Business Days
$5,678.00 /Each
True Refrigeration TCIM-522-HA1-A/TIB-422-A Description
The True TCIM-522-HA1-A/TIB-422-A ice machine combo has a dispenser head and 320-pound capacity collection bin. Under optimal conditions, the air-cooled machine head produces 447 pounds of ice; however, warmer temperatures bring this production down. The bin can hold a maximum of 320 pounds at a time.
To control the True TCIM-522-HA1-A/TIB-422-A, a digital control panel is provided for access to production time and amounts, diagnostics, and cleaning settings. The type of ice produced is half cubed—ideal for use in soft drinks, teas, and water. To ensure the freshness of the ice, the lining of the collection bin is coated in antimicrobial TrueGuard, slowing the development of mildew and mold between cleanings.
- True Ice
- 447-lb. of ice over 24 hours with 70-degree F ambient air/ 50-degree F incoming water
- 375-lb. of ice over 24 hours in ambient temperature of 90 degrees F/ incoming water 70 degrees
- Half-cube ice
- Ice dimensions: 7⁄16 in. L x 1 1⁄8 in. W x 7⁄8 in. H
- Truetech aluminum exterior finish
- TrueGuard-coated components
- TrueNcapsuL8 insulation and evaporator seal
- Air-cooled condenser
- Digital, touch screen display
- Ice level monitoring
- Remote monitoring, data access, and shut off
- R290 refrigerant
- 320-lb. capacity
- Sloped front
- Antimicrobial imbedded plastic interior
- Truetech aluminum exterior finish
- Ice maker head: 22 in. W x 24 in. D x 22 in. H
- Ice bin: 22 in. W x 34 in. D x 50 in. H
- 115 V/ 60 Hz/ 1 ph
*Image may not depict product color, inclusions or accessories.
*Free shipping on True Refrigeration TCIM-522-HA1-A/TIB-422-A within the 48 contiguous states.
From The Manufacturer
True Ice Series Ice Maker, cube style (half), self-contained, air-cooled condenser, 22"W x 24"D x 22"H, up to 550 lb. production/24 hr, TrueNcapsuL8 insulated & sealed evaporator, TrueGuard built-in Anti Microbial, advanced electronic control with 4.3" touch display, Ice level monitoring, Truetech aluminum exterior finish, R290 Hydrocarbon Refrigerant, UL EPH Classified, cULus, ENERGY STAR®
True Ice Series Ice Storage Bin, slope front, 22" wide, 320 lb. bin storage 22"W x 34"D x 50"H, Antimicrobial imbedded plastic interior, Truetech aluminum exterior finish, UL EPH Classified, cULus
True Refrigeration TCIM-522-HA1-A/TIB-422-A Specifications
| Spec Attribute | Spec Value |
|---|---|
| Manufacturer | True Refrigeration |
| 24 Hr. Production (lb) | 550 |
| Access | Lift Up Door |
| Bin Capacity (lb) | 320 |
| Compressor Type | Air Cooled |
| Depth (in) | 34 |
| Height (in) | 72 |
| Hertz | 60 |
| Ice Type | Half Cube |
| Kitchen Innovations Awards | 2024 |
| Phase | 1 |
| Product | Ice Machines with Bins |
| Product Type | Ice Makers & Bins |
| Rating | Better |
| Refrigerant | R290 (Hydrocarbon) |
| Series | True Ice Series |
| Suggested Use | Commercial |
| Voltage | 115 |
| Warranty | 3-year Parts & Labor; 5-year Parts & Labor Evaporator; 5-year Compressor |
| Water Inlet (in) | 0.5 |
| Width (in) | 22 |
| Weight | 304.00 |
Important Prop 65 information for California residents.
Compare to Similar Items
| Attributes |
True Refrigeration TCIM-522-HA1-A/TIB-422-A True TCIM-522-HA1-A/TIB-422-A 550 lb True Ice Series Half Cube Ice Machine w/ Bin - 320 lb Storage, Air Cooled, 115v Current Item |
Hoshizaki KM-522MAK/B-300SF |
Manitowoc Ice IYP0620A/D420 |
|
|---|---|---|---|---|
| Customer Rating |
|
|
|
|
| Price | $5,678.00 / Each | $6,360.00 / Each | $5,372.00 / Each | $5,894.00 / Each |
| Shipping | Free Shipping | Free Shipping | Free Shipping | Free Shipping |
| Lead Time | QUICK SHIP: Typically ships in 1 - 3 Business Days | IN STOCK: Ships in 1 Business Day | Typically ships in 9 - 13 Business Days | QUICK SHIP: Ships in 1 Business Day |
| Ice Type | Half Cube | Crescent Cube | Half Cube | Half Cube |
| 24 Hr. Production (lb) | 550 | 548 | 464 | 537 |
| Width (in) | 22 | 22 | 22 | 22 |
| Bin Capacity (lb) | 320 | 300 | 370 | 383 |
| Compressor Type | Air Cooled | Air Cooled | Air Cooled | Air Cooled |
| Rating | Better | Best | Best | Best |
| Height (in) | 72 | 74 | 73 | 71.5 |
| Refrigerant | R290 (Hydrocarbon) | R290 (Hydrocarbon) | R290 (Hydrocarbon) | R290 (Hydrocarbon) |
| Voltage | 115 | 115 | 115 | 115 |
| Warranty | 3-year Parts & Labor; 5-year Parts & Labor Evaporator; 5-year Compressor | 3-year Parts & Labor; 5-year Evaporator Parts & Labor; 5-year Compressor & Condenser Parts | Commercial: 3-year Parts & Labor; 5-year Parts & Labor Evaporator; 5-year Compressor & Condenser Parts; Residential: 1-year Parts & Labor | Machine: 3-year Parts & Labor, 5-year Compressor Parts; Dispenser: 3-year Parts & Labor |
