Hoshizaki KMD-505MWJ 30" Crescent Cube Ice Machine Head - 592 lb/24 hr, Water Cooled, 115v/1ph
QUICK SHIP: Typically ships in 1 - 3 Business Days
Free Shipping Item
$4,335.00 /Each
Contact us for details!
Selected Compressor Type: Water Cooled
White Glove Delivery
Contact your sales rep for availability
Attention: Order by 05-01-2025 to save before the price increases!
Hoshizaki KMD-505MWJ Description
Featuring a water-cooled condenser, the Hoshizaki KMD-505MWJ ice maker head is ideal for busy locations with water circulating chiller systems. When incoming water is 50 degrees Fahrenheit and the ambient air is 70 degrees, the unit can produce 592 pounds of ice in a day. As incoming water in water-cooled systems is often cooler than ambient air, ice production is likely to be consistently high.
For proper operation of the Hoshizaki KMD-505MWJ, a separate purchase of a collection bin is required. The unit must be hardwired into the locations electrical system; this unit does not include a plug. The self-diagnostic program works with the EverCheck™ alert system to notify operators of any issues as they arise. Most issues will be automatically addressed, reducing the need for user intervention.
Product Details
- KMEdge X series
- 592-lb. daily production under ideal conditions
- Ideal conditions: 70-deg. F air, 50-deg. F incoming water
- Cresent half-cube ice
- Ice dimensions: 11/8 in x 11/2 in. x 1/2 in.
- Stainless steel exterior finish
- Self-contained, water-cooled condenser
- CycleSaver™ design
- Self-diagnostic programming
- EverCheck alert system
- Snap-fit parts
- R404a refrigerant
- Bin required for operation
Dimensions & Utilities
- 30 in. W x 24 in. D x 22 in. H
- 11 A
- 115 V/60 Hz/ 1 ph (hardwired)
Product Features
*Free shipping on Hoshizaki KMD-505MWJ within the 48 contiguous states.
From The Manufacturer
Ice Maker, Cube-Style, 30"W, water-cooled, self-contained condenser, production capacity up to 592 lb/24 hours at 70°50° (436 lb AHRI certified at 90°/70°), stainless steel finish, crescent cube style, R-404A refrigerant, 115v/60/1-ph, 11 amps, NSF, UL (Replaces KMD-460MWJ, KMD-530MWJ, KML-500MWJ)
*Image may not depict product color, inclusions or accessories.
3-year Parts & Labor; 5-year Evaporator Parts & Labor; 5-year Compressor & Condenser Parts
Watch a video about this product
Hoshizaki KMD-505MWJ Specifications
| Spec Attribute | Spec Value |
|---|---|
| Manufacturer | Hoshizaki |
| 24 Hr. Production (lb) | 592 |
| Compressor Type | Water Cooled |
| Depth (in) | 24 |
| Height (in) | 22 |
| Ice Type | Crescent Cube |
| Phase | 1 |
| Product | Ice Machine Heads |
| Product Type | Ice Makers & Bins |
| Rating | Best |
| Refrigerant | R404A |
| Series | KM EDGE X |
| Voltage | 115 |
| Warranty | 3-year Parts & Labor; 5-year Evaporator Parts & Labor; 5-year Compressor & Condenser Parts |
| Width (in) | 30 |
| Weight | 176.00 |
Documents
Important Prop 65 information for California residents.
Replacement for the Following Items
- Hoshizaki KMD460MWJ
- Hoshizaki KMD530MWJ
- Hoshizaki KML500MWJ
