True TS-23-1-G-1-HC~FGD01 27" One Section Reach In Refrigerator, (1) Glass Door & (1) Solid Door, Left Hinge, 115v

The True TS-23-1-G-1 reach-in refrigerator has one solid, left-hinged half door on the bottom and one glass left-hinged half door on top. Its bottom glass door is made with double-pane, thermal glass to keep light outside the refrigerator from negatively impacting the temperature inside of the unit, and it provides product visibility without opening the door. Both doors are self-closing and include standard door locks to prevent unauthorized access. Cold air is retained with magnetic gaskets around the frames.

The temperature of the unit is set between 33 and 38 degrees Fahrenheit by R290 hydrocarbon refrigerant, while temperature recovery is quick since the evaporator fan motor and large fan blades create high-volume airflow. LED interior lighting brightens the cabinet interior to enhance visibility. PVC-coated, wire shelves adjust to accommodate various product sizes, and the True TS-23-1-G-1 refrigerator has a bottom-mounted condensing unit to simplify maintenance accessibility. Designed to be used with preventative maintenance practices, the compressor fan motor directs air in an opposite direction when turned on. This 20-second motion helps eliminate collection of dust, dust, and debris from the condensing coil to improve its operation.

Product Details

• Durable, corrosion-resistant stainless steel construction
• Upper half door is made of double-pane thermal glass so users can view products
• Solid half door is built with 12-in. recessed handle
• Both doors self-close and have standard door locks to prevent unauthorized access
• Welded steel frame rail is black powder coated for corrosion resistance
• 4-in.-diameter stem castors provide mobility
• Foamed-in-place polyurethane insulation retains cold air in the cabinet
• 3 PVC-coated, gray wire shelves are adjustable to accommodate various products
• Shelves adjustable in ¹⁄₂-in. increments
• LED lights shine on product for visibility
• Epoxy coated evaporator resists corrosion
• Temperature holding range: 33-38 degrees F
• Exterior has a solar, digital display for temperature monitoring
• Self-contained capillary tube refrigeration system uses R290 hydrocarbon refrigerant to keep temperatures cool
• Condenser and evaporator fan motors push air through the cabinet for even distribution
• Condensing coil buildup removed with reverse condensing fan motor mechanism
• Bottom-mount condenser is great for hot environments since warm air rises

Dimensions & Utilities

• Shelves: 22⁷⁄₈ in. W x 23¹⁄₄ in. D
• Overall: 27 in. W x 31¹⁄₈ in. D x 83³⁄₈ in. H
• 2.2 A, ¹⁄₄ HP
• 115 V/60 Hz/1 ph, 9-ft. cord with NEMA 5-15P plug

*Free shipping on True Refrigeration TS-23-1-G-1-HC~FGD01 within the 48 contiguous states.

From The Manufacturer

Refrigerator, reach-in, one-section, framed glass door version 01, (1) glass & (1) stainless steel half doors, (3) gray PVC coated adjustable wire shelves, LED interior lighting, stainless steel front/sides, stainless steel interior, 4" castors, R290 Hydrocarbon refrigerant, 1/4 HP, 115v/60/1-ph, 2.2 amps, NEMA 5-15P, cULus, UL EPH Classified

*Not as Shown - Left Hinge

Additional Product Information

Cord Attached

This product includes a cord and plug

Natural Refrigerant

Product made with Hydrocarbon Refrigerants

7-year Parts & Labor; 7-year Compressor
