TG Series - Pass-Thru Heated Cabinet
Model TG1HPT-1G-1S - 1 Glass Front / 1 Solid Back Swing Doors, 31 Cu. Ft.
TRUE - 100% Manufactured in America - Over 60 years experience - Best In Class 2001-2008 Eight Consecutive Years
- Provides cabinet holding temperature of 80 degree F to 180 degree F (26.67 degree C to 822 degree C).
- Internal fan provides low velocity, forced-air heat distribution to assure even temperatures throughout the cabinet.
- (2) stainless steel 1000 watt finned tube heating elements per section for uniform generation of electric heat. Cabinet comes with a total of 2000 watts.
- 300 series stainless steel door, front, and bottom. The very finest stainless; higher tensile strength for fewer dents and scratches.
- Anodized aluminum interior cabinet liner. 300 series stainless steel door liner and floor with coved corners.
- Three (3) adjustable, heavy duty chrome plated wire shelves 25'L x 27 3/4'D (635 mm x 705 mm) with 1' (26 mm) standoff. Four (4) chrome plated shelf clips to be included per shelf.
- Entire cabinet structure and solid doors are foamed-in-place using high density, CFC free, polyurethane insulation.
- Positive seal self-closing doors with 120 degree stay open feature. Lifetime guaranteed door hinges and recessed door handles. Optional Features / Accessories, Up-charge and lead times may apply
- 4' (102 mm) diameter swivel castors.
- Seismic/flanged legs.
- All stainless steel legs.
- Stainless steel (electro polished) shelves.
- Chrome shelves.
- Universal pan slides.
- #1 pan slides.
- #2 rod style pan slides.
- Curb mountable units.
- Export units - consult factory.
- Prison package options - consult factory.
- Metal door handle.
- Kit #1: Nine sets of #1 type tray slides, bottom support of one 18' x 26' (456 mm x 661 mm) pan or two 14' x 18' (356 mm x 456 mm) pans.
- Kit #2: One set half-section #2 steel rod tray slides, rim support of one 18' x 26' (456 mm x 661 mm) pan.
- Kit #3: Six sets of universal type tray slides, bottom support of one 18'x 26'(456 mm x 661 mm) pan, two 14'x18' (356 mm x 456 mm) pans or two 12' x 20' (305 mm x 508 mm) pans.
- Kit #4: Three chrome shelves 25'L x 27 3/4'D (635 mm x 705 mm) with 1' (26 mm) standoff and chrome plated shelf supports. Warranty Info
- 1 year warranty on all parts and labor
- Additional 4 year on compressor. (U.S.A. only) Installation Manual
- View Installation Manuals for True Refrigeration Equipment
SPEC SERIES Pass-thru Heated Cabinet, stainless steel front, aluminum sides, (1) glass door front, (1) stainless steel door rear, locks, cam-lift hinges, digital temperature control, aluminum interior, (3) gray shelves, 5" castors, 1.5KW, NEMA 6-15P, 208-230v/60/1, 9' cord, MADE IN USA
*The warranty will not be honored for residential or non-commercial use of any Commercial Equipment.
True Refrigeration STG1HPT-1G-1S SpecificationsPDF Spec Sheet
|Size||Full Height (69" +)|
|Specialty Options||Pass Thru|
|Also Known As||TG1HPT-1G-1S, TRUE TG1HPT-1G-1S, TRUTG1HPT1G1S, 890TG1HPT1G1S, TG1HPT1G1S|
|Category||Pass Thru/Specialty Heated Cab|
|Doors||Full Clear/ Full Solid|
