True TCIM-422-HA1-A 22" Half Cube Ice Machine Head - 443 lb/24 hr, Air Cooled, 115v/1ph
QUICK SHIP: Typically ships in 1 - 3 Business Days
$3,894.00 /Each
True Refrigeration TCIM-422-HA1-A Description
The True TCIM-422-HA1-A half-cube ice machine head can produce 443 pounds of ice daily when ambient air is 90 degrees Fahrenheit and the water is 70 degrees Fahrenheit. The self-contained refrigeration system uses eco-friendly R290 hydrocarbon coolant. This unit is constructed with high-efficiency fans. The high- and low-pressure transducers moderate and transcribe data to the operator. The external body of this unit is constructed of aluminum, and the plastic pieces and interior are protected with TrueGuard antimicrobial to inhibit bacteria and mold growth.
The True TCIM-422-HA1-A half-cube ice machine head is controlled via an electronic control system. The system’s display measures 4 3⁄10 inches and has simple-touch operation for ease of control. This touchscreen communicates current diagnostic statuses through alarms and push notifications. Time-of-flight ice sensors moderate frost amounts for user convenience. Based on establishment traffic, this unit’s touchscreen permits employees to adjust ice production rates to fit the current need. The air filter can be removed; however, its RCU technology, self-cleans when needed.
- 443-lb. production/24 hr
- Truetech aluminum exterior finish
- TrueGuard antimicrobial embedded in every plastic piece
- Simple-to-remove food zone pieces
- Removable air filter with RCU technology
- Head only (bin sold separately)
- 4 3⁄10-in. front display
- Simple touch operation
- 1-touch cleaning
- Intuitive diagnostic system
- Alarms and push notifications
- Programmable ice production rate
- Time-of-flight ice sensors
- Uses environmentally safe R290 hydrocarbon refrigerant
- Sealed, fully insulated evaporator
- High- and low-pressure transducers
- Mirco-channel condenser
- Ultra-quiet fan operation
- Wide operating range between 35 and 110 degrees F
- Water pressure range: 20-100 PSI
- 22 in. W x 24 in. D x 22 in. H
- 104-127 V/60 Hz/1 ph
*Image may not depict product color, inclusions or accessories.
*Free shipping on True Refrigeration TCIM-422-HA1-A within the 48 contiguous states.
From The Manufacturer
True Ice Series Ice Maker, cube style (half), self-contained, air-cooled condenser, 22"W x 24"D x 22"H, up to 443 lb. production/24 hr, TrueNcapsuL8 insulated & sealed evaporator, TrueGuard built-in Anti Microbial, advanced electronic control with 4.3" touch display, Ice level monitoring, Truetech aluminum exterior finish, R290 Hydrocarbon Refrigerant, UL EPH Classified, cULus, ENERGY STAR®
True Refrigeration TCIM-422-HA1-A Specifications
| Spec Attribute | Spec Value |
|---|---|
| Manufacturer | True Refrigeration |
| 24 Hr. Production (lb) | 443 |
| Compressor Type | Air Cooled |
| Depth (in) | 24 |
| Height (in) | 22 |
| Ice Type | Half Cube |
| Phase | 1 |
| Product | Ice Machine Heads |
| Product Type | Ice Makers & Bins |
| Rating | Better |
| Refrigerant | R290 (Hydrocarbon) |
| Suggested Use | Commercial |
| Voltage | 115 |
| Warranty | 3-year Parts & Labor; 5-year Parts & Labor Evaporator; 5-year Compressor Parts & Labor |
| Water Inlet (in) | 0.5 |
| Width (in) | 22 |
| Weight | 165.00 |
Important Prop 65 information for California residents.
Compare to Similar Items
| Attributes |
True Refrigeration TCIM-422-HA1-A True TCIM-422-HA1-A 22" Half Cube Ice Machine Head - 443 lb/24 hr, Air Cooled, 115v/1ph Current Item |
|||
|---|---|---|---|---|
| Customer Rating |
|
|
|
|
| Price | $3,894.00 / Each | $4,028.00 / Each | $4,260.00 / Each | $3,842.00 / Each |
| Shipping | Free Shipping | Free Shipping | Free Shipping | Free Shipping |
| Lead Time | QUICK SHIP: Typically ships in 1 - 3 Business Days | QUICK SHIP: Ships in 1 Business Day | Typically ships in 4 - 8 Business Days | QUICK SHIP: Typically ships in 1 - 3 Business Days |
| 24 Hr. Production (lb) | 443 | 436 | 489 | 356 |
| Ice Type | Half Cube | Half Cube | Crescent Cube | Half Cube |
| Compressor Type | Air Cooled | Air Cooled | Air Cooled | Air Cooled |
| Width (in) | 22 | 22 | 22 | 22 |
| Rating | Better | Best | Best | Best |
| Voltage | 115 | 115 | 115 | 115 |
| Refrigerant | R290 (Hydrocarbon) | R290 (Hydrocarbon) | R404A | R404A |
| Warranty | 3-year Parts & Labor; 5-year Parts & Labor Evaporator; 5-year Compressor Parts & Labor | 3-year Parts & Labor; 5-year Evaporator Parts & Labor ; 5-year Compressor Parts; 3-year Compressor Labor | 3-year Parts & Labor; 5-year Evaporator Parts & Labor; 5-year Compressor & Condenser Parts | Commercial: 3-year Parts & Labor; 5-year Parts & Labor Evaporator; 5-year Compressor & Condenser Parts; Residential: 1-year Parts & Labor |
