Manitowoc Ice IDP0620W/D420 528 lb Indigo NXT™ Full Cube Ice Machine w/ Bin - 383 lb Storage, Water Cooled, 115v
Typically ships in 1 - 3 Business Days
$6,202.00 /Each
Contact us for details!
Selected Compressor Type: Water Cooled
Selected Ice Type: Full Cube
Manitowoc Ice IDP0620W/D420 Description
The Manitowoc Ice IDP0620W-161/D420 Indigo NXT™ ice maker with bin can produce 528 pounds in 24 hours and stores 383 pounds. Ice production can be programmed based on desired volume or time of operation. It makes 0.875-inch by 0.875-inch by 0.875-inch full-cube ice, which is perfect for regular drinks and alcoholic beverages that need slow-melting cubes. However, it does not cool drinks as quickly as smaller ice types.
A sensing probe measures ice thickness with sound waves, ensuring each ice production cycle is consistent. Offering straightforward operation, the touchscreen display enables users to check service and energy information. Users can access components through the food zone door since it has a hinged, swing-out design.
The Manitowoc Ice IDP0620W-161/D420 ice machine with bin has a polyurethane bin liner that resists scratching and supports cleaning. Its bin door is insulated with foam, so it retains cold air and slows the melting process. Users can open the door from different angles since grips are included on the front, right, and left sides. Its self-latching design ensures that the door remains open while staff are scooping.
- Part of the Indigo NXT series
- 528-lb. daily ice production capacity
- Full-cube ice size: 0.875 in. x 0.875 in. x 0.875 in.
- Acoustical sensing probe measures the thickness of ice to check for consistency
- Ice production can be controlled by time or volume
- easyTouch® display has menu, energy, and service settings
- 24-hr. preventive maintenance and diagnostic feedback
- Hinged food zone door swings out for component access
- Removable distribution tube, water trough, sensing probes, and curtain
- AlphaSan® antimicrobial agent on integral components slows bacteria growth
- Stainless steel exterior is coated in clear, smudge-resistant DuraTech™
- Water-cooled motor
- Uses R290 refrigerant
- 5,400 average BTU; 6,300 peak BTU
- Required ambient air temperature: 40-110 degrees F
- Required incoming water temperature: 40-90 degrees F
- Required incoming water pressure: 20-80 PSI
- 383-lb. application capacity
- 12.9-cu.-ft. AHRI-certified capacity
- Blue polyurethane bin liner
- Foamed door insulation delays melting
- Door's center, left, and right grips enable opening from different angles
- Self-latching door stays open when scooping
- 5.3-lb. capacity in the ice scoop
- Scoop has a built-in knuckle and thumb guard that protects the ice from hands
- DuraTech exterior
- Ice Maker
- 22 in. W x 24.5 in. D x 21.5 in. H
- 11.6 A, 4.13 kW
- 115 V/60 Hz/1 ph
- Bin
- 22 in. W x 34 in. D x 50 in. H
*Image may not depict product color, inclusions or accessories.
*Free shipping on Manitowoc Ice IDP0620W/D420 within the 48 contiguous states.
From The Manufacturer
Indigo NXT™ Series Ice Maker, cube-style, water-cooled, self-contained condenser, 22"W x 24.5"D x 21.5"H, production capacity up to 528 lb/24 hours at 70°/50° (468 lb AHRI certified at 90°/70°), easyTouch display with 13 different language options, date/time stamp display, automatic reminder/alert icon, one touch asset information, automatic detection of accessories, continuous operating status, programmable production options (time, weight, day or night), one touch cleaning with displayed instructions, Alpha-San anti-microbial protection, acoustical ice sensing probe, self-diagnostic technology, DuraTech™ exterior, half-dice size cubes, R290 refrigerant, NSF, cULus, CE
Ice Bin, 22"W, 34"D x 50"H, with side-hinged front-opening door, side grips, 383 lbs. application capacity, AHRI certified 12.9 cu. ft., for top-mounted ice maker, Duratek exterior, NSF
Watch a video about this product
Manitowoc Ice IDP0620W/D420 Specifications
| Spec Attribute | Spec Value |
|---|---|
| Manufacturer | Manitowoc Ice |
| 24 Hr. Production (lb) | 528 |
| Access | Lift Up Door |
| Also Known As | IDT0620W/D420 |
| Bin Capacity (lb) | 383 |
| Compressor Type | Water Cooled |
| Depth (in) | 34 |
| Height (in) | 71.5 |
| Hertz | 60 |
| Ice Type | Full Cube |
| Kitchen Innovations Awards | 2011 |
| Kitchen Innovations Awards | 2019 |
| Phase | 1 |
| Product | Ice Machines with Bins |
| Product Type | Ice Makers & Bins |
| Rating | Best |
| Refrigerant | R290 (Hydrocarbon) |
| Series | Indigo NXT™ |
| Suggested Use | Commercial |
| Voltage | 115 |
| Warranty | Machine: 3-year Parts & Labor, 5-year Compressor Parts; Dispenser: 3-year Parts & Labor |
| Water Inlet (in) | 0.38 |
| Width (in) | 22 |
| Weight | 248.00 |
