Manitowoc Ice AR-20000 Single Primary Water Filter Cartridge Assembly, Tank

Image may not depict product color, inclusions or accessories.

KaTom #: 399-AR20000 • MPN: AR-20000

IN STOCK: Ships in 1 Business Day

(0 reviews)Write a Review
Retail Price: $812.00
$349.99 / Each

Image may not depict product color, inclusions or accessories.

Manitowoc Ice AR-20000 Description

Manitowoc Ice

The Manitowoc AR-20000 Arctic Pure® primary water filter assembly has 1-micron particle reduction. The cartridge has a capacity of 20,000 gallons of water, which should enable it to last about 6 months in most uses. A 40-gram scale inhibitor reduces the amount of scale buildup in the ice machine, which can help prolong the life of that critical piece of equipment. This filter is made for ice machines that produce between 601 and 1,000 pounds of ice every 24 hours. Automatic shut-off and pressure relief valves help protect both the assembly and the ice machine from damage caused by changes in supply pressure. The quick-change-housing design of the Manitowoc AR-20000 Arctic Pure primary water filter assembly makes changing the cartridge easier and faster, and minimizes contamination during change out. In areas that have low water quality where large particles of sediment are present, the Manitowoc AR-PRE pre-filter should be installed upstream on the water supply to prolong the service lives of both the primary filter and ice machine.

Product Details

  • 1-micron particle reduction
  • 20,000-gal. capacity
  • 40-gm. scale inhibitor to reduce limescale buildup in ice machine
  • Made for ice machines that produce between 601-1,000 lbs. of ice daily
  • Quick change housing design minimizes contamination during change-out
  • Automatic shut-off and pressure relief valves protect filter and ice machine
  • Overall dimensions: 5.72 in. W x 4 in. D x 21.34 in. H
  • NSF certified

Compatible Manitowoc Ice Machines

  • I-906
  • I-1000
  • IB-890C
  • IB-1090C
  • RN-1078C
  • RF/RFS-0650
  • RF-0644
  • RF/RFS-1278C
  • RF/RFS-1279R
  • RF-1200

Benefits of water filters are covered in our water filters buyers' guide.

Arctic PureĀ® Primary Water Filter Assembly, includes head, shroud, hardware, mounting assembly, & (1) filter cartridge, 20,000 gallon capacity, 601-1,000 lbs./ice per day

*The warranty will not be honored for residential or non-commercial use of any Commercial Equipment.

Warning Small Important Prop 65 information for California residents.

Manitowoc Ice AR-20000 Specifications

PDF Spec Sheet
Manufacturer Manitowoc Ice
Also Known As AR-20000
Suggested Use Ice Makers (Manifold System)
Water Flow 0.75 gpm
For Use With 601-1000 lbs Production/day
Product Cartridge Assembly
Part Type Ice Maker Filter
Product Type Ice Makers & Bins
Special Features Assembly & Cartridge
Weight 5.00
