Southbend S36D-1GL 36" 4 Burner Gas Range with Griddle, NG

Image may not depict product color, inclusions or accessories.

KaTom #: 348-S36D1GNG • MPN: S36D-1GL NG
Ships Free

Extended Lead Time (14+ days)

(0 reviews)Write a Review
Web Price: $3,105.00

Selected Gas Type: Natural Gas

Image may not depict product color, inclusions or accessories.

Southbend S36D-1GL Description


The Southbend S36D-1G NG S-series restaurant range is equipped with four 28,000 BTU, cast iron, no-clog burners with cast iron grates that heat evenly and are virtually indestructible. Underneath the burners sits a crumb drawer that catches debris and grease to making cleaning underneath a simpler process. The 12-inch griddle is built with a 12-inch-thick griddle plate and a smooth polished surface. Since the edges of the griddle are raised, grease it kept from making a mess on the rest of the unit.

The standard oven base is heated by a heavy-duty "U"-shaped burner to evenly distribute heat. The interior is insulated on five sides with rock wool for energy efficiency. One removable rack has two rack guide positions. If the pilot light goes out, the flame failure safety device will shut off the flow of gas to the unit. The Southbend S36D-1G NG S-series restaurant range is heated with natural gas.

Product Details

  • Heated with natural gas
  • Front rail measures 4-in. for transferring products, plating food, and helping prevent burns
  • Knobs are each marked with a red stripe to help cooks quickly adjust burners to the desired level
  • Lower valve panel is hinged for convenient access to gas shutoff valves
  • Rugged, 6-in. steel legs for adjusting height and leveling range
  • Gas pressure regulator comes factory installed for safety and consistent heat
  • Stainless steel shelf, sides, and front
  • Overall Dimensions: 3612 in. W x 34 in. D 5912 in. H
  • cCSAus, CSA-Gas, and CSA-Design listed; NSF certified

Cast Iron Burners

  • 4 cast iron, no-clog, 28,000 BTU burners
  • Crumb tray underneath burners captures debris and grease to facilitate cleaning
  • Cast iron grates are removable and offer even heat distribution
  • Rear grates accommodate stock pots up to 14-in. in dia.

12-Inch Griddle

  • 12-in. griddle heated with a 18,000 BTU burner
  • 12-in. thick plated spreads heat evenly for reduced hot spots
  • Smooth polished surface helps prevent food from sticking
  • Manual controls give operator direct control over intensity of burner flame
  • On the left side of the unit

Standard Oven Base

  • Thermostat provides accurate temperature controls and has range of 175-550 degrees F
  • Heavy-duty "U"-Shaped 35,000 BTU burner for even heating
  • Quadrant spring doors with chrome handles are rugged and easy to operate
  • Flame failure safety device shuts off gas supply if pilot flame goes out
  • Oven is insulated on five sides with dense, self-supporting rock wool for energy efficiency
  • 1 removable oven rack is included and adjustable on two positions
  • Entire oven interior is enameled for corrosion resistance, simple cleaning, and even temperatures throughout
  • Oven Interior Dimensions: 26 in. W x 2612 in. D x 14 in. H

S-Series Restaurant Range, NG gas, 36", (4) 28,000 BTU open burners, (1) 12" griddle left, manual controls, (1) standard oven, snap action thermostat, removable cast iron grate tops & crumb drawer, hinged lower valve panel, includes (1) rack, stainless steel front, sides, shelf, 4" front rail & 6" adjustable legs, 165,000 BTU, cCSAus, CSA Flame, CSA Star, NSF

*The warranty will not be honored for residential or non-commercial use of any Commercial Equipment.

Warning Small Important Prop 65 information for California residents.

Southbend S36D-1GL Specifications

PDF Spec Sheet
Manufacturer Southbend
Application Restaurant
Base Standard Oven
BTU / Burner 28000
Gas Type NG
Heat Gas
Range Configuration Burners
Range Configuration Griddle
Width (in) 36
Width (in) Range 30 - 39 in
Product Type Ranges
Product Gas Range
Weight 535.00
