Southbend 4601DD-3GR 60" 4 Burner Gas Range w/ Griddle & (2) Standard Ovens, Natural Gas
$13,281.00 /Each
Call for details!
Selected Gas Type: Natural Gas
Ship times may vary due to supply chain constraints. Please contact our Sales Team if you need this item in a specified time frame.
Southbend 4601DD-3GR Description
Southbend's Ultimate Restaurant range gives operators three of the most essential pieces of equipment in one convenient package. Four 33,000 BTU cast iron burners give you the power you need to boil and sauté. Two ovens give you plenty of room to bake, and each can accommodate a full-size sheet pan front-to-back or side-to-side. A 1⁄2-inch thick griddle provides an evenly-heated surface to grill proteins and breakfast items.
- 37-in. high cooking top is at a comfortable working height for staff
- Non-clog 33,000 BTU top burners
- Rugged cast iron burner grates are removable for cleaning
- 4-in. deep stainless steel front plate for plating food
- Manually-controlled gas cutoff valve on the front of the range cuts off gas to entire range for safety and easy servicing
- Gas regulator is factory installed
- Standing pilot light to ignite top burners
- Stainless steel front, sides, and shelf
- Removable drip trays catch crumbs and grease for easy cleaning
- Runs on natural gas
- 22 1⁄2 in. flue riser with shelf included
- Overall Dimensions: 34-in. W x 34-in. D x 59 1⁄2 in. H
- 45,000 BTU input each
- 175 to 550 degree F thermostatic controls
- Oven interiors are porcelain enameled for even heating and easy cleaning
- Oven interior dimensions measure 26-in. W x 26 1⁄2 in. D x 14-in. H
- 1⁄2-in. thick polished steel griddle plate is made for even heating
- Raised sides help capture grease and facilitate cleaning
- Manual heat controls give users control over heat intensity
- Griddle is located on the right side of the cooktop
*Image may not depict product color, inclusions or accessories.
*Free shipping on Southbend 4601DD-3GR within the 48 contiguous states.
- Comparing Commercial Range Configurations
- Learn How to Choose the Right Commercial Range
- Base Options for Commercial Ranges
- What to Know Before Buying a Commercial Gas Range
- Cleaning Your Commercial Hood
- Gas vs Electric Ranges
- Natural Gas vs Propane
- Range Cleaning and Maintenance Tips
- What is a Commercial Range?
- Choosing the Right Range Configuration
- Commercial Range Repair and Troubleshooting
From The Manufacturer
Ultimate Restaurant Range, natural gas, 60", (4) non-clog burners, standard grates, (1) 36" griddle right, standing pilot, (2) standard ovens with battery spark ignition, includes (1) rack per oven, 22-1/2" flue riser with shelf, stainless steel front, sides, shelf & 6" adjustable legs, 286,000 BTU, cCSAus, CSA Flame, CSA Star, NSF
Southbend 4601DD-3GR Specifications
| Spec Attribute | Spec Value |
|---|---|
| Manufacturer | Southbend |
| Additional Info | Contact Customer Service for altitudes above 2,000 feet |
| Application | Restaurant |
| Base | Standard Oven |
| BTU / Burner | 33000 |
| Burner Configuration | Standard |
| Burner Style | Grates |
| Burner Type(s) | Open |
| Controls | Manual |
| Depth (in) | 34 |
| Gas Inlet Size | 0.75 |
| Gas Type | NG |
| Griddle Location | Right |
| Griddle Width (in) | 36 |
| Heat | Gas |
| Height (in) | 59.5 |
| Installation Type | Freestanding |
| Max Temp | 550 |
| Number of Burners | 4 |
| Number of Ovens | Double |
| Open Burner BTU (ea) | 33000 |
| Plate Thickness (in) | 1/2 |
| Product | Gas Ranges |
| Product Type | Cooking Equipment |
| Rack Positions per Standard Oven | 2 |
| Racks per Standard Oven | 1 |
| Range Configuration | Burners/Griddle |
| Rating | Better |
| Series | Ultimate |
| Special Features | Spark Ignition |
| Standard Oven BTU/hr | 45000 |
| Standard Oven Dimensions | 26"W x 26.5"D x 14"H |
| Total BTU | 286000 |
| Vent | Backriser w/ hi-shelf |
| Warranty | 1-year Limited Parts & Labor |
| Width (in) | 60 |
| Weight | 1075.00 |
