Southbend 4601DD-3GR 60" 4 Burner Gas Range w/ Griddle & (2) Standard Ovens, Liquid Propane
$13,281.00 /Each
Call for details!
Selected Gas Type: Liquid Propane
Ship times may vary due to supply chain constraints. Please contact our Sales Team if you need this item in a specified time frame.
Southbend 4601DD-3GR Description
Southbend's 4601DD-3GR LP Ultimate Restaurant range provides some of the most essential foodservice functions in one economic package. With it, you get four non-clog burners, a 36-inch griddle, and two standard ovens. The restaurant range is made with a stainless steel front, sides, and shelf, so it is designed to hold up under challenging kitchen conditions while remaining easy to clean. A 37 inch working height and 27 inch cooking surface depth make the range comfortable and easy to operate.
- Ergonomic 37-in. working height for operator comfort
- Stainless steel, 4-in. deep front rail
- Manual gas shut-off valve is located at the front of the range for safety and convenient access to turn off gas to the entire range
- Factory-installed gas pressure regulator keeps gas flowing at safe, optimal pressure
- 4 non-clogging, 24,000 BTU cast iron burners
- Heavy-duty cast iron burner grates distribute heat evenly and are simple to maintain
- Removable drip tray catches grease and crumbs underneath burners
- Top burners are lit by standing pilot light
- Overall Dimensions: 34-in. W x 34-in. D x 59 1⁄2 in. H
- Smooth, polished, 1⁄2 in. thick griddle plate
- Raised sides contain grease for safety and easy cleaning
- Manually-controlled gives users control over heat intensity
- Griddle is located to the left of the burners
- 40,000 BTU input per oven
- Electronic spark ignition helps conserve gas by eliminating the need for a standing pilot light
- 175 to 550 degree thermostatic controls
- Porcelain-enameled interiors make for easy cleaning and even heating throughout
- Oven interiors measure 26-in. W x 24-in. D x 14-in. H
- Each oven accommodates full-size sheet pans both front-to-back and side-to-side
- One rack is included per oven and each is adjustable on two positions
*Image may not depict product color, inclusions or accessories.
*Free shipping on Southbend 4601DD-3GR within the 48 contiguous states.
- Comparing Commercial Range Configurations
- Learn How to Choose the Right Commercial Range
- Base Options for Commercial Ranges
- What to Know Before Buying a Commercial Gas Range
- Cleaning Your Commercial Hood
- Gas vs Electric Ranges
- Natural Gas vs Propane
- Range Cleaning and Maintenance Tips
- What is a Commercial Range?
- Choosing the Right Range Configuration
- Commercial Range Repair and Troubleshooting
From The Manufacturer
Ultimate Restaurant Range, liquid propane gas, 60", (4) non-clog burners, standard grates, (1) 36" griddle right, standing pilot, (2) standard ovens with battery spark ignition, includes (1) rack per oven, 22-1/2" flue riser with shelf, stainless steel front, sides, shelf & 6" adjustable legs, 250,000 BTU, cCSAus, CSA Flame, CSA Star, NSF
Southbend 4601DD-3GR Specifications
| Spec Attribute | Spec Value |
|---|---|
| Manufacturer | Southbend |
| Additional Info | Contact Customer Service for altitudes above 2,000 feet |
| Application | Restaurant |
| Base | Standard Oven |
| BTU / Burner | 24000 |
| Burner Configuration | Standard |
| Burner Style | Grates |
| Burner Type(s) | Open |
| Controls | Manual |
| Depth (in) | 34 |
| Gas Inlet Size | 0.75 |
| Gas Type | LP |
| Griddle Location | Right |
| Griddle Width (in) | 36 |
| Heat | Gas |
| Height (in) | 59.5 |
| Installation Type | Freestanding |
| Max Temp | 550 |
| Number of Burners | 4 |
| Number of Ovens | Double |
| Open Burner BTU (ea) | 24000 |
| Plate Thickness (in) | 1/2 |
| Product | Gas Ranges |
| Product Type | Cooking Equipment |
| Rack Positions per Standard Oven | 2 |
| Racks per Standard Oven | 1 |
| Range Configuration | Burners/Griddle |
| Rating | Better |
| Series | Ultimate |
| Special Features | Spark Ignition |
| Standard Oven BTU/hr | 45000 |
| Standard Oven Dimensions | 26"W x 26.5"D x 14"H |
| Total BTU | 250000 |
| Vent | Backriser w/ hi-shelf |
| Warranty | 1-year Limited Parts & Labor |
| Width (in) | 60 |
| Weight | 1075.00 |
