Vulcan V6B36C 36" 6 Burner Gas Range w/ Convection Oven, Liquid Propane
Retail Price: $44,835.00
$18,456.00 /Each
Selected Gas Type: Liquid Propane
Vulcan V6B36C Description
The Vulcan V6B36C gas range is propane powered with six open top burners. Since there are lift-off heads on the burners, the components of the range can be easily accessed. For flexible cooking, the burners have individual pilots and controls. The aeration bowls on the heavy-duty cast grates add structure to the grates’ fingers and help direct heat up to the pots and pans. Messes are kept off the walls and floors with a 4-inch stainless steel stub riser.
The convection oven can be set between 175 and 550 degrees Fahrenheit. Most baked-on product releases easily from porcelain so the interior is easy to clean. There are three position options for the two racks in the oven of the Vulcan V6B36C gas range, providing operators with versatile cooking choices. The heavy-duty door construction, fully welded frame, and stainless steel construction provide durability for heavy use. The range is elevated off floors with 6-inch adjustable legs.
- LP gas powered
- (6) 35,000 burners have an open top design
- Lift-off burner heads provide access to the components
- Each burner has its own pilot and controls for flexibility
- Heavy-duty cast grates have aeration bowls to direct heat to pots and pans
- 4-in. stub riser helps keep messes off walls and floors
- 6-in. legs can be adjusted for uneven surfaces
- Stainless steel stub back, base, sides, burner box, front top ledge, and front are easy to clean and will not scratch easily
- 1⁄4-in. dia. front gas manifold with 1 1⁄4 rear gas connection
- 242,000 BTU
- Overall Dimensions: 36 in. W x 36 3⁄4 in. D x 36 in. H
- Adjust the thermostat from 175-550 degrees F
- Porcelain interior is easy to clean since most baked-on product easily releases
- 2 racks can be positioned at 3 heights
- Door stands up to commercial use since it is heavy duty
- Counter weight door hinges
- Interior Dimensions: 27 in. W x 27 in. D x 13 in. H
*Image may not depict product color, inclusions or accessories.
*Free shipping on Vulcan V6B36C within the 48 contiguous states.
- Comparing Commercial Range Configurations
- Learn How to Choose the Right Commercial Range
- Base Options for Commercial Ranges
- What to Know Before Buying a Commercial Gas Range
- Cleaning Your Commercial Hood
- Gas vs Electric Ranges
- Natural Gas vs Propane
- Range Cleaning and Maintenance Tips
- What is a Commercial Range?
- Choosing the Right Range Configuration
- Commercial Range Repair and Troubleshooting
From The Manufacturer
V Series Heavy Duty Range, gas, 36", (6) 35,000 BTU open burners, cast iron grates, convection oven, stainless steel front, front top ledge, sides, base, burner box & stub back, 6" adjustable legs, 242,000 BTU, CSA, NSF
Vulcan V6B36C Specifications
| Spec Attribute | Spec Value |
|---|---|
| Manufacturer | Vulcan |
| Additional Info | Contact Customer Service for altitudes above 2,000 feet |
| Application | Heavy Duty |
| Base | Convection Oven |
| BTU / Burner | 35000 |
| Burner Configuration | Standard |
| Burner Style | Grates |
| Burner Type(s) | Open |
| Controls | Thermostatic |
| Convection Oven BTU/hr | 32000 |
| Convection Oven Dimensions | 27"W x 27"D x 13"H |
| Depth (in) | 36.75 |
| Gas Inlet Size | 1.25 |
| Gas Type | LP |
| Heat | Gas/Electric |
| Height (in) | 36 |
| Hertz | 60 |
| Installation Type | Freestanding |
| Max Temp | 550 |
| Number of Burners | 6 |
| Number of Ovens | Single |
| Open Burner BTU (ea) | 35000 |
| Phase | 1 |
| Product | Gas Ranges |
| Product Type | Cooking Equipment |
| Rack Positions per Convection Oven | 3 |
| Racks per Convection Oven | 2 |
| Range Configuration | Burners |
| Rating | Best |
| Series | V Series |
| Total BTU | 242000 |
| Vent | Stub Riser |
| Voltage | 115 |
| Warranty | 1-year Limited Parts & Labor |
| Width (in) | 36 |
| Weight | 730.00 |
