Vulcan started producing equipment in Louisville Ky., more than 150 years ago. Today, the brand produces state-of-the-art cooking appliances, including fryers, ovens, and everything in between. The brand is owned by Illinois Tool Works, a global manufacturing leader.
Vulcan V336HC 36" Gas Range w/ (3) Hot Tops & Convection Oven, Natural Gas
Typically ships in 4 - 6 weeks
Free Shipping Item
$18,943.00 /Each
Low price guarantee - call us!
Selected Gas Type: Natural Gas
Liquid Propane
Ship times may vary due to supply chain constraints. Please contact our Sales Team if you need this item in a specified time frame.
White Glove Delivery
Contact your sales rep for availability
Attention: Order by 06-01-2025 to save before the price increases!
Vulcan V336HC Description
The Vulcan V336HC gas range combines three high-output hot tops with a convection oven base, offering a versatile solution for high-volume cooking. This 36-inch-wide range uses natural gas to deliver 122,000 total BTU, including 32,000 BTU directed to the convection oven. The oven interior is constructed of porcelain on the bottom, sides, and door panel to enhance heat reflection and simplify cleaning. Two racks are included and can be arranged in three positions, while a heavy-duty oven door with counterweight hinges opens smoothly for convenient access.
To withstand the demands of commercial kitchens, the Vulcan V336HC features stainless steel construction across the front, sides, base, stub back, top ledge, and burner box. Each of the three hot tops produces 30,000 BTU and is crafted of heavy-duty cast iron to retain heat and reduce hot spots. Operators can adjust heat independently using individual burner controls and pilots. The unit is mounted on 6-inch adjustable stainless steel legs and includes a 11⁄4-inch front gas manifold with a capped rear connection. A 4-inch stub riser protects surfaces behind the unit from radiant heat.
Product Details
- From the V Series
- Stainless steel construction
- (3) 30,000 BTU hot top burners
- Heavy-duty cast iron hot top surfaces
- Includes 3/4-in. ground steel griddle plate
- Individual pilots and controls for each burner
- 11⁄4-in. front gas manifold and capped 11⁄4-in. rear gas connection
- 4-in. stainless steel stub riser
- 6-in. adjustable stainless steel legs
Convection Oven
- 32,000 BTU oven burner
- Porcelain interior includes bottom, sides, and door panel
- Temperature range: 175–550 degrees F
- Includes 2 oven racks adjustable in 3 positions
- Heavy-duty door with counterweight hinges
Dimensions & Utilities
- Oven interior: 27 in. W x 27 in. D x 13 in. H
- Overall: 36 in. W x 417⁄8 in. D x 401⁄2 in. H
- 115 V/60 Hz/1 ph, 9-ft. cord with plug
- 4 A
- Powered by liquid propane
- 122,000 total BTU
Product Features
*Free shipping on Vulcan V336HC within the 48 contiguous states.
From The Manufacturer
V Series Heavy Duty Range, gas, 36", (3) hot tops, convection oven, stainless steel front, front top ledge, sides, base, burner box & stub back, 6" adjustable legs, 122,000 BTU, CSA, NSF
*Image may not depict product color, inclusions or accessories.
1-year Limited Parts & Labor
Vulcan V336HC Specifications
| Spec Attribute | Spec Value |
|---|---|
| Manufacturer | Vulcan |
| Application | Heavy Duty |
| Base | Convection Oven |
| BTU / Burner | 30000 |
| Burner Configuration | Standard |
| Burner Style | None |
| Burner Type(s) | None |
| Depth (in) | 41.87 |
| Gas Type | NG |
| Heat | Gas |
| Height (in) | 40.5 |
| Installation Type | Freestanding |
| Number of Burners | None |
| Number of Ovens | Single |
| Product | Gas Ranges |
| Product Type | Cooking Equipment |
| Rack Positions per Convection Oven | 3 |
| Racks per Convection Oven | 2 |
| Range Configuration | Hot Top |
| Rating | Best |
| Series | V Series |
| Total BTU | 122000 |
| Vent | Stub Back |
| Warranty | 1-year Limited Parts & Labor |
| Width (in) | 36 |
| Weight | 655.00 |
Residential Users: This unit is not to be installed or operated in a residential or other non-commercial setting. Check local codes to ensure your foodservice kitchen is properly equipped for this piece. Use in an improper setting will void the warranty and the manufacturer will not provide parts or labor coverage for damage, failure, or other issues with the product. While this product may be covered by a manufacturer's warranty, vendor assumes no liability for product failure or any damages/injuries.
WARNING: Important Prop 65 information for California residents.
