Vulcan V336HC 36" Gas Range w/ 3 Hot Tops & Convection Oven, Natural Gas
Retail Price: $46,816.00
$15,663.65 /Each
Selected Gas Type: Natural Gas
Attention: Order by 12-01-2026 to save before the price increases!
Vulcan V336HC Description
The Vulcan V336HC gas range combines three high-output hot tops with a convection oven base, offering a versatile solution for high-volume cooking. This 36-inch-wide range uses natural gas to deliver 122,000 total BTU, including 32,000 BTU directed to the convection oven. The oven interior is constructed of porcelain on the bottom, sides, and door panel to enhance heat reflection and simplify cleaning. Two racks are included and can be arranged in three positions, while a heavy-duty oven door with counterweight hinges opens smoothly for convenient access.
To withstand the demands of commercial kitchens, the Vulcan V336HC features stainless steel construction across the front, sides, base, stub back, top ledge, and burner box. Each of the three hot tops produces 30,000 BTU and is crafted of heavy-duty cast iron to retain heat and reduce hot spots. Operators can adjust heat independently using individual burner controls and pilots. The unit is mounted on 6-inch adjustable stainless steel legs and includes a 1 1⁄4-inch front gas manifold with a capped rear connection. A 4-inch stub riser protects surfaces behind the unit from radiant heat.
- From the V Series
- Stainless steel construction
- (3) 30,000 BTU hot top burners
- Heavy-duty cast iron hot top surfaces
- Includes 3⁄4-in. ground steel griddle plate
- Individual pilots and controls for each burner
- 1 1⁄4-in. front gas manifold and capped 1 1⁄4-in. rear gas connection
- 4-in. stainless steel stub riser
- 6-in. adjustable stainless steel legs
- 32,000 BTU oven burner
- Porcelain interior includes bottom, sides, and door panel
- Temperature range: 175–550 degrees F
- Includes 2 oven racks adjustable in 3 positions
- Heavy-duty door with counterweight hinges
- Oven interior: 27 in. W x 27 in. D x 13 in. H
- Overall: 36 in. W x 41 7⁄8 in. D x 40 1⁄2 in. H
- 115 V/60 Hz/1 ph, 9-ft. cord with plug
- 4 A
- Powered by liquid propane
- 122,000 total BTU
*Image may not depict product color, inclusions or accessories.
*Free shipping on Vulcan V336HC within the 48 contiguous states.
- Comparing Commercial Range Configurations
- Learn How to Choose the Right Commercial Range
- Base Options for Commercial Ranges
- What to Know Before Buying a Commercial Gas Range
- Cleaning Your Commercial Hood
- Gas vs Electric Ranges
- Natural Gas vs Propane
- Range Cleaning and Maintenance Tips
- What is a Commercial Range?
- Choosing the Right Range Configuration
- Commercial Range Repair and Troubleshooting
From The Manufacturer
Vulcan V336HC Specifications
| Spec Attribute | Spec Value |
|---|---|
| Manufacturer | Vulcan |
| Application | Heavy Duty |
| Base | Convection Oven |
| BTU / Burner | 30000 |
| Burner Configuration | Standard |
| Burner Style | None |
| Burner Type(s) | None |
| Depth (in) | 41.87 |
| Gas Type | NG |
| Heat | Gas |
| Height (in) | 40.5 |
| Installation Type | Freestanding |
| Number of Burners | None |
| Number of Ovens | Single |
| Product | Gas Ranges |
| Product Type | Cooking Equipment |
| Rack Positions per Convection Oven | 3 |
| Racks per Convection Oven | 2 |
| Range Configuration | Hot Top |
| Rating | Best |
| Series | V Series |
| Total BTU | 122000 |
| Vent | Stub Back |
| Warranty | 1-year Limited Parts & Labor |
| Width (in) | 36 |
| Weight | 655.00 |
