Vulcan V336HC 36" Gas Range w/ (3) Hot Tops & Convection Oven, Liquid Propane
Typically ships in 4 - 6 weeks
Free Shipping Item
$18,943.00 /Each
Low price guarantee - call us!
Selected Gas Type: Liquid Propane
Natural Gas
Ship times may vary due to supply chain constraints. Please contact our Sales Team if you need this item in a specified time frame.
White Glove Delivery
Contact your sales rep for availability
Attention: Order by 06-01-2025 to save before the price increases!
Vulcan V336HC Description
Featuring a single convection oven and three solid-top burners, the Vulcan V336HC gas range combines stovetop power with enclosed baking capabilities. Designed for liquid propane, it delivers a total of 122,000 BTU, including 32,000 BTU dedicated to the convection oven. The oven can be set between 175 and 550 degrees Fahrenheit, and its porcelain interior—including the bottom, sides, and door panel—simplifies cleaning while promoting even heat distribution. Staff can choose from three rack positions for the two included oven racks, and the heavy-duty oven door features counterweight hinges for smooth opening and closing.
Part of the V Series, the Vulcan V336HC features three 30,000-BTU hot tops constructed of heavy-duty cast iron to retain and distribute heat evenly across cookware. The range’s front, sides, top ledge, base, burner box, and stub back are made of stainless steel to withstand daily use in high-volume kitchens. For precise temperature management, each burner is controlled individually with dedicated pilots. The 11⁄4-inch front gas manifold and capped rear connection simplify utility access, while 6-inch adjustable legs stabilize the unit on uneven floors. A 4-inch stub riser helps protect surrounding surfaces from heat.
Product Details
- Part of the V Series
- Made of stainless steel
- (3) 30,000 BTU hot top burners
- Heavy-duty cast iron hot top surfaces
- Includes 3/4-in. ground steel griddle plate
- Individual pilots and controls per burner
- 11⁄4-in. front gas manifold and capped 11⁄4-in. rear gas connection
- 4-in. stainless steel stub riser
- 6-in. adjustable stainless steel legs
- 122,000 total BTU
Convection Oven
- 32,000 BTU oven burner
- Porcelain interior includes bottom, sides, and door panel
- Temperature range: 175–550 degrees F
- Includes 2 oven racks and 3 rack positions
- Heavy-duty door with counterweight hinges
Dimensions & Utilities
- Oven interior: 27 in. W x 27 in. D x 13 in. H
- Overall: 36 in. W x 417⁄8 in. D x 401⁄2 in. H
- 115 V/60 Hz/1 ph, 9-ft. cord with plug
- 4 A
- Powered by liquid propane
*Free shipping on Vulcan V336HC within the 48 contiguous states.
From The Manufacturer
V Series Heavy Duty Range, gas, 36", (3) hot tops, convection oven, stainless steel front, front top ledge, sides, base, burner box & stub back, 6" adjustable legs, 122,000 BTU, CSA, NSF
*Image may not depict product color, inclusions or accessories.
1-year Limited Parts & Labor
Vulcan V336HC Specifications
| Spec Attribute | Spec Value |
|---|---|
| Manufacturer | Vulcan |
| Application | Heavy Duty |
| Base | Convection Oven |
| BTU / Burner | 30000 |
| Burner Configuration | Standard |
| Burner Style | None |
| Burner Type(s) | None |
| Depth (in) | 41.87 |
| Gas Type | LP |
| Heat | Gas |
| Height (in) | 40.5 |
| Installation Type | Freestanding |
| Number of Burners | None |
| Number of Ovens | Single |
| Product | Gas Ranges |
| Product Type | Cooking Equipment |
| Rack Positions per Convection Oven | 3 |
| Racks per Convection Oven | 2 |
| Range Configuration | Hot Top |
| Rating | Best |
| Series | V Series |
| Total BTU | 122000 |
| Vent | Stub Back |
| Warranty | 1-year Limited Parts & Labor |
| Width (in) | 36 |
| Weight | 655.00 |
Residential Users: This unit is not to be installed or operated in a residential or other non-commercial setting. Check local codes to ensure your foodservice kitchen is properly equipped for this piece. Use in an improper setting will void the warranty and the manufacturer will not provide parts or labor coverage for damage, failure, or other issues with the product. While this product may be covered by a manufacturer's warranty, vendor assumes no liability for product failure or any damages/injuries.
