Vulcan V236HB 36" Gas Range w/ 2 Hot Tops & Storage Base, Natural Gas
Retail Price: $27,135.00
$9,208.34 /Each
Selected Gas Type: Natural Gas
Attention: Order by 12-01-2026 to save before the price increases!
Vulcan V236HB Description
Built with dual 18-inch-wide hot top sections, the Vulcan V236HB gas range supports heavy-duty back-of-house operations with two individually controlled burners. The hot tops are constructed of heavy-duty cast iron to retain and distribute heat evenly across the surface. Beneath the tops, a 3⁄4-inch-thick ground steel plate provides structural durability for constant thermal exposure. Operators can fine-tune each section using front-mounted pilot valves and burner controls to accommodate a variety of cooking applications.
For streamlined storage, the Vulcan V236HB V series gas range includes a cabinet base with stainless steel doors, internal rack guides, and one removable shelf. Its stainless steel construction offers corrosion resistance and long-term durability. A 4-inch stainless steel stub riser protects the rear wall from heat and splatter, while the unit stands securely on 6-inch adjustable stainless steel legs. Gas enters through a 1⁄4-inch-diameter front manifold, and a capped rear gas connection is included for flexible utility access.
- From the V series
- Made of stainless steel
- 2 sections
- Heavy-duty cast hot top plates
- 3⁄4-in. ground steel griddle plate
- (2) 30,000 BTU hot top burners
- Individual pilots and burner controls
- 1⁄4-in.-diameter front gas manifold
- Capped rear gas connection
- Cabinet base with stainless steel doors
- Universal rack guides with 1 removable shelf
- 4-in. stub riser
- Mounted on 6-in. adjustable legs
- 36 in. W x 41 7⁄8 in. D x 40 1⁄2 in. H
- 60,000 total BTU
- Powered by natural gas
*Image may not depict product color, inclusions or accessories.
*Free shipping on Vulcan V236HB within the 48 contiguous states.
- Comparing Commercial Range Configurations
- Learn How to Choose the Right Commercial Range
- Base Options for Commercial Ranges
- What to Know Before Buying a Commercial Gas Range
- Cleaning Your Commercial Hood
- Gas vs Electric Ranges
- Natural Gas vs Propane
- Range Cleaning and Maintenance Tips
- What is a Commercial Range?
- Choosing the Right Range Configuration
- Commercial Range Repair and Troubleshooting
From The Manufacturer
Vulcan V236HB Specifications
| Spec Attribute | Spec Value |
|---|---|
| Manufacturer | Vulcan |
| Application | Heavy Duty |
| Base | Storage |
| BTU / Burner | 30000 |
| Burner Configuration | Standard |
| Burner Style | None |
| Burner Type(s) | None |
| Depth (in) | 41.88 |
| Gas Type | NG |
| Heat | Gas |
| Height (in) | 40.5 |
| Installation Type | Freestanding |
| Number of Burners | None |
| Number of Ovens | No Oven |
| Product | Gas Ranges |
| Product Type | Cooking Equipment |
| Range Configuration | Hot Top |
| Rating | Best |
| Series | V Series |
| Total BTU | 60000 |
| Vent | Stub Back |
| Warranty | 1-year Limited Parts & Labor |
| Width (in) | 36 |
| Weight | 550.00 |
