Vulcan V236HB 36" Gas Range w/ (2) Hot Tops & Storage Base, Liquid Propane
Typically ships in 4 - 6 weeks
Free Shipping Item
$10,979.00 /Each
Low price guarantee - call us!
Selected Gas Type: Liquid Propane
Natural Gas
Ship times may vary due to supply chain constraints. Please contact our Sales Team if you need this item in a specified time frame.
White Glove Delivery
Contact your sales rep for availability
Attention: Order by 06-01-2025 to save before the price increases!
Vulcan V236HB Description
Equipped with a cabinet-style base, the Vulcan V236HB gas range includes stainless steel doors, rack guides, and one removable shelf to support kitchen storage. Designed for durability in high-volume environments, the exterior is made of corrosion-resistant stainless steel. To protect surrounding surfaces during use, a 4-inch stub riser is positioned at the rear, and the unit stands on 6-inch adjustable stainless steel legs to maintain stability on uneven floors.
Atop the Vulcan V236HB gas range, two full-width hot top sections deliver steady, even heat through a pair of individually controlled 30,000 BTU burners. The cast iron hot tops retain heat efficiently, and the 3⁄4-inch-thick ground steel plate offers a durable surface for cooking. Each burner has its own pilot and control system, enabling precise temperature regulation. Gas flows through a 1⁄4-inch-diameter front manifold, with a capped rear gas connection included for layout flexibility.
Product Details
- V series
- Made of stainless steel
- 2 hot top sections
- Heavy-duty cast hot top plates
- 3⁄4-in. ground steel griddle plate
- (2) 30,000 BTU hot top burners
- Individual pilots and burner controls
- 1⁄4-in.-diameter front gas manifold
- Capped rear gas connection
- Cabinet base with stainless steel doors
- Universal rack guides with 1 removable shelf
- 4-in. stub riser
- Mounted on 6-in. adjustable legs
Dimensions & Utilities
- 36 in. W x 417⁄8 in. D x 401⁄2 in. H
- 60,000 total BTU
- Powered by LP gas
Product Features
*Free shipping on Vulcan V236HB within the 48 contiguous states.
From The Manufacturer
V Series Heavy Duty Range, gas, 36", (2) hot tops, cabinet base, stainless steel front, front top ledge, sides, base, burner box & stub back, 6" adjustable legs, 60,000 BTU, CSA, NSF
*Image may not depict product color, inclusions or accessories.
1-year Limited Parts & Labor
Vulcan V236HB Specifications
| Spec Attribute | Spec Value |
|---|---|
| Manufacturer | Vulcan |
| Application | Heavy Duty |
| Base | Storage |
| BTU / Burner | 30000 |
| Burner Configuration | Standard |
| Burner Style | None |
| Burner Type(s) | None |
| Depth (in) | 41.88 |
| Gas Type | LP |
| Heat | Gas |
| Height (in) | 40.5 |
| Installation Type | Freestanding |
| Number of Burners | None |
| Number of Ovens | No Oven |
| Product | Gas Ranges |
| Product Type | Cooking Equipment |
| Range Configuration | Hot Top |
| Rating | Best |
| Series | V Series |
| Total BTU | 60000 |
| Vent | Stub Back |
| Warranty | 1-year Limited Parts & Labor |
| Width (in) | 36 |
| Weight | 550.00 |
Residential Users: This unit is not to be installed or operated in a residential or other non-commercial setting. Check local codes to ensure your foodservice kitchen is properly equipped for this piece. Use in an improper setting will void the warranty and the manufacturer will not provide parts or labor coverage for damage, failure, or other issues with the product. While this product may be covered by a manufacturer's warranty, vendor assumes no liability for product failure or any damages/injuries.
