Vulcan started producing equipment in Louisville Ky., more than 150 years ago. Today, the brand produces state-of-the-art cooking appliances, including fryers, ovens, and everything in between. The brand is owned by Illinois Tool Works, a global manufacturing leader.
Vulcan MSA24 24" Gas Griddle w/ Thermostatic Controls - 1" Steel Plate, Natural Gas
Typically ships in 4 - 8 Business Days
Free Shipping Item
$5,431.00 /Each
Selected Gas Type: Natural Gas
White Glove Delivery
Contact your sales rep for availability
Attention: Order by 06-01-2025 to save before the price increases!
Vulcan MSA24 Description
The Vulcan MSA24 natural gas griddle has two burners with individual thermostats and a temperature range of 200 to 550 degrees Fahrenheit. The griddle plate is made of polished steel that evenly distributes heat and is 1 inch thick to resist warping. The sides, front, and front top ledge have a heavy-duty stainless steel construction. The unit has a bull-nose front that stays cool to the touch to protect against injury. Grease is collected in the trough, goes through the fully welded grease chute, and is sent to the grease drawer for disposal.
The Vulcan MSA24 natural gas griddle uses manual ignition for greater gas usage control. It has pilot safety valves that prevent leaks by shutting off the gas supply if the flame goes out. A 3⁄4-inch connector and pressure regulator are provided for easy setup. Chrome guards on the knobs protect against damage and give it an attractive, professional look.
Product Details
- Heated with natural gas
- (2) 27,000-BTU burners with independent thermostats offer full temperature control
- 1-in.-thick polished steel plate is resistant to warping
- Temperature range: 200-550 degrees F
- Stainless steel front top ledge, front, and sides are heavy duty
- Bull-nose design in the front keeps surfaces cool to prevent injuries
- Back and side splashes prevent grease, oil, and food debris from reaching other surfaces
- Frame is completely welded for strength
- Fully welded grease chute is resistant to migration
- Grease drawer can hold 6 qt.
- Ignites manually for gas control
- Pilot safety valve ensures the gas is turned off if the flame goes out
- Low profile enables many installation options
- Chrome knob guards add durability
- Bottom heat guards protect countertops against heat
- Comes with a pressure regulator and rear connector for easy installation
- Works with Vulcan clamshells to provide two-sided grilling (sold separately)
- 54,000 BTU
- Overall dimensions: 24 in. W x 311⁄2 in. D x 151⁄4 in. H
*Free shipping on Vulcan MSA24 within the 48 contiguous states.
From The Manufacturer
Heavy Duty Griddle, countertop, natural gas, 24" W x 24" D cooking surface, 1" thick polished steel griddle plate, embedded mechanical snap action thermostat every 12", millivolt pilot safety, manual ignition, low profile, stainless steel front, sides, front grease trough, 4" back & tapered side splashes, 4" adjustable legs, 54,000 BTU, CSA, NSF
*Image may not depict product color, inclusions or accessories.
Resources
1-year Limited Parts & Labor
Watch a video about this product
Vulcan MSA24 Specifications
| Spec Attribute | Spec Value |
|---|---|
| Manufacturer | Vulcan |
| Application | Heavy Duty |
| BTU / Burner | 27,000 |
| Control Spacing (in) | 12 |
| Controls | Thermostatic |
| Cooking Area Depth (in) | 24 |
| Cooking Area Width (in) | 24 |
| Gas Type | NG |
| Heat | Gas |
| Overall Width (in) | 24 |
| Plate Material | Steel |
| Plate Thickness (in) | 1 |
| Product | Griddles |
| Product Type | Countertop Cooking Equipment |
| Rating | Better |
| Series | MSA Series |
| Warranty | 1-year Limited Parts & Labor |
| Width (in) | 24 |
| Weight | 265.00 |
Residential Users: This unit is not to be installed or operated in a residential or other non-commercial setting. Check local codes to ensure your foodservice kitchen is properly equipped for this piece. Use in an improper setting will void the warranty and the manufacturer will not provide parts or labor coverage for damage, failure, or other issues with the product. While this product may be covered by a manufacturer's warranty, vendor assumes no liability for product failure or any damages/injuries.
