Hatco S-30 Imperial Booster Water Heater, 16 Gallon, 30 kW, 208v/3ph
Retail Price: $8,411.00
$4,626.05 /Each
Selected Voltage: 208V, 3 Phase
| 208V, 3 Phase |
| 208V, 1 Phase |
| 240V, 1 Phase |
| 240V, 3 Phase |
| 480V, 3 Phase |
Hatco S-30 Description
Finished in powder-coated hammertone, the Hatco S-30 Imperial booster water heater resists dents and scratches. Holding 16 gallons, this unit provides hot water to sanitize and flash-dry dishes and flatware. Fiberglass insulation and the built-in heat trap ensure reduced heat loss. Before shipping, this unit is pre-wired and pre-plumbed at the factory for swift installation anywhere in the kitchen.
To ensure it runs properly, the Hatco S-30 booster water heater includes a temperature-relief valve and a pressure-reducing valve. Two gauges and a pilot indicator light enable staff to monitor the unit in operation. When working with a low-temperature dishwasher, users can lower the temperature to 140 degrees Fahrenheit. Safety features include a high-temperature limit control and low-water cut-off.
- 16-gal. capacity
- Maximum 301 GPH at 40-degree-F rise
- Maximum 172 GPH at 70-degree-F rise
- Thermostat set to 180-degree-F sanitizing temperatures
- Adjustable to 140 degrees F for low-temp machines
- Castone®-lined tank prevents limescale
- Silver powder-coated, hammertone body finish
- Stainless steel front panel facilitates cleaning
- Fiberglass insulation
- Built-in heat trap
- Temperature-relief valve
- Pressure-reducing valve
- 2 pressure gauges
- Pilot indicator light
- Operated by an on/off switch
- High-temperature limit control and low-water cut-off prevent permanent damage
- 28.53 in. W x 22.75 in. D x 31.03 in. H
- 88.3 A, 30 kW
- 208 V/60 Hz/3 ph
*Image may not depict product color, inclusions or accessories.
*Free shipping on Hatco S-30 within the 48 contiguous states.
From The Manufacturer
Hatco S-30 Specifications
| Spec Attribute | Spec Value |
|---|---|
| Manufacturer | Hatco |
| 40F Recovery (gph) | 301 |
| 70F Recovery (gph) | 172 |
| Amps | 88.3 |
| Capacity (gallons) | 16 |
| Heat | Electric |
| Hertz | 60 |
| kW | 30 |
| Phase | 3 |
| Product | Booster Heaters |
| Product Type | Dishwashing Equipment & Supplies |
| Series | Imperial |
| Usage Level | Heavy Duty |
| Voltage | 208 |
| Warranty | 1-year Parts & Labor; 10-year Tank Parts |
| Watts | 21 - 30 |
| Width (in) | 23.5 |
| Weight | 214.00 |
Important Prop 65 information for California residents.
Compare to Similar Items
| Attributes |
Hatco S-30 Hatco S-30 Imperial Booster Water Heater, 16 Gallon, 30 kW, 208v/3ph Current Item |
|||
|---|---|---|---|---|
| Customer Rating |
|
|
|
|
| Price | $4,626.05 / Each | $4,626.05 / Each | $4,626.05 / Each | $4,626.05 / Each |
| Shipping | Free Shipping | Free Shipping | Free Shipping | Free Shipping |
| Usage Level | Heavy Duty | Heavy Duty | Heavy Duty | Heavy Duty |
| 40F Recovery (gph) | 301 | 301 | 301 | 301 |
| 70F Recovery (gph) | 172 | 172 | 172 | 172 |
| Capacity (gallons) | 16 | 16 | 16 | 16 |
| Width (in) | 23.5 | 23.5 | 23.5 | 23.5 |
| Watts | 21 - 30 | 21 - 30 | 21 - 30 | 21 - 30 |
| Heat | Electric | Electric | Electric | Electric |
| Voltage | 208 | 480 | 240 | 240 |
| Warranty | 1-year Parts & Labor; 10-year Tank Parts | 1-year Parts & Labor; 10-year Tank Parts | 1-year Parts & Labor; 10-year Tank Parts | 1-year Parts & Labor; 10-year Tank Parts |
- 5
- 4
- 3
- 2
- 1
Review this product!
It requires 208 V/3 ph electrical service.
The heating capacity is 30 kW.
The internal tank holds 16 gal.
Inlet and outlet connections use 3⁄4-in. NPT fittings.
Overall dimensions measure 28 9⁄16 in. W x 22 3⁄4 in. D x 31 in. H with standard legs installed.
A low-water cut-off shuts off the heating elements when water levels drop.
The front panel removes to provide access to internal components.
