True T-23FG-HC~FGD01 27" T Series One Section Reach In Freezer, (1) Left Hinge Glass Door, 115v
$7,485.80 /Each
Selected Hinge: Left Hinge
Ship times may vary due to supply chain constraints. Please contact our Sales Team if you need this item in a specified time frame.
True Refrigeration T-23FG-HC~FGD01 Description
This True T-23FG-HC~FGD01 reach-in freezer maintains -10 degrees Fahrenheit with R290 hydrocarbon refrigerant, which is controlled by a capillary tube system. Large evaporator and condenser fans push high volumes of cold air through the cabinet to consistently cool products, while rear guards keep product out of the way of airflow. An automatic defrost system turns on at a specific time and shuts off at a specific temperature.
This unit's reverse condensing fan motor technology helps clean off buildup from a condensing coil. Over time, dirt, dust, and debris can inhibit coil operation, and this 20-second blowing mechanism can help eliminate damaging collection for improved operation. Despite this mechanism's efficiency, users should continue to practice preventative maintenance on the condensing coil.
This reach-in includes three PVC-coated shelves that are adjustable in 1⁄2-inch increments along cabinet pilasters to accommodate various product sizes. Resisting stains and scratches, the interior of the True T-23FG-HC~FGD01 one-section freezer is finished with a clear coat over aluminum, and stainless steel floors have coved corners to simplify cleanup since debris does not get trapped. To open on the right, the glass door is left hinged.
- 1 left-hinged glass door opens on the right
- Door lock protects valuable products
- 15-in. extruded aluminum handle provides interior access
- 1-piece door gasket snaps in magnetically and can be removed without tools
- Stainless steel front and aluminum top, back, and sides
- Cabinet interior is finished with clear coat over aluminum
- Interior floor is made of stainless steel with coved corners
- Foamed-in-place polyurethane insulation retains cold air
- Black powder-coated frame rail is built for a long service life
- 4-in. castors are fitted to rail for mobility
- 3 wear-resistant, PVC-coated shelves adjust in 1⁄2-in. increments
- LED lights illuminate the interior
- Airflow guards prevent product from obstructing airflow
- Operating temperature: -10 degrees F
- Exterior-mounted temperature dial displays interior temperature
- Epoxy-coated evaporator is corrosion resistant
- Capillary tube system controls refrigerant flow
- Uses R290 hydrocarbon refrigerant
- Large evaporator and condenser fan motors consistently move air in the cabinet
- Condensing fan motor blows in a reverse direction for 20 seconds upon start up
- Bottom-mount condensing unit is accessible
- Defrost system initiates automatically on a timer and terminates when it detects the proper temperatures
- Shelves: 22 7⁄8 in. W x 23 1⁄4 in. D
- Overall: 27 in. W x 31 1⁄4 in. D x 83 3⁄8 in. H
- 6.2 A, 3⁄4 HP
- 115 V/60 Hz/1 ph, 9-ft. cord with a NEMA 5-15P plug
*Not as Shown - Left Hinge
*Free shipping on True Refrigeration T-23FG-HC~FGD01 within the 48 contiguous states.
From The Manufacturer
Freezer, reach-in, one-section, -10°F, framed glass door version 01, (1) glass door, (3) PVC coated adjustable wire shelves, LED interior lighting, stainless steel front, aluminum sides, clear coated aluminum interior with stainless steel floor, 4" castors, R290 Hydrocarbon refrigerant, 3/4 HP, 115v/60/1-ph, 6.2 amps, NEMA 5-15P, cULus, UL EPH Classified
True Refrigeration T-23FG-HC~FGD01 Specifications
| Spec Attribute | Spec Value |
|---|---|
| Manufacturer | True Refrigeration |
| Compressor Location | Bottom |
| Cubic Feet | 20.8 |
| Depth (in) | 31.25 |
| Door Design | Full |
| Door Type | Glass |
| Height (in) | 83.38 |
| Hertz | 60 |
| Hinge Configuration | Left |
| Interior Material | Aluminum |
| NEMA | 5-15P |
| Phase | 1 |
| Product | Reach-In Freezers |
| Product Type | Commercial Refrigeration |
| Rating | Better |
| Refrigerant | R290 (Hydrocarbon) |
| Sections | 1 |
| Series | T Series |
| Special Features | Casters Included - Uninstalled |
| Type | Reach In |
| Voltage | 115 |
| Warranty | 7-year Parts & Labor; 7-year Compressor |
| Width (in) | 27 |
| Weight | 330.00 |
