True STG1RPT-1G-1G-HC 27 1/2" One Section Pass Thru Refrigerator, 2 Right Hinge Glass Doors, 115v
$8,551.96 /Each
True Refrigeration STG1RPT-1G-1G-HC Description
The True STG1RPT-1G-1G-HC SPEC SERIES® one-section pass-thru refrigerator has double-pane, thermal-insulated glass doors let users see inside. For corrosion resistance, the exterior has a durable stainless steel front to match the aluminum sides. Doors have a stay-open feature, enabling users to load product more efficiently, while a bolt-style lock prevents theft and unauthorized access. Its interior has aluminum side walls and back, and the ceiling and floor are constructed of stainless steel.
The True STG1RPT-1G-1G-HC one-section reach-in refrigerator's refrigeration unit is top mounted to stop unauthorized employees from tampering with the system. A factory-engineered, self-contained capillary tube meters R290 hydrocarbon refrigerant to keep the unit at a set temperature between 33 and 38 degrees Fahrenheit. Evaporator and condenser fan motors move a consistent volume of air to reduce heat production and energy consumption. Improving the unit's function and extending its life, the compressor's fan motor cleans the condensing coil. Each time the compressor turns on, the fan blows backwards, removing excess dust and dirt from the coil. This feature along with regular maintenance helps improve overall product temperatures.
- Part of the SPEC SERIES
- Stainless steel front matches sides constructed of corrosion-resistant aluminum
- Interior has aluminum side walls and back with a stainless steel ceiling and floor
- Low-E, double-pane doors have thermal-insulated glass
- Interior insulated with foamed-in-place polyurethane
- 3 PVC-coated wire shelves support product
- 4 external cam-lift door hinges per door section
- Door remains open at 120 degrees for loading
- Bolt-style door lock prevents unauthorized access
- Magnetic door gaskets are constructed of 1 piece and removable for cleaning
- Safety-shielded, LED lighting illuminates the interior
- Exterior digital temperature display enables user to monitor temperatures
- Unit is pre-wired at factory
- Factory-engineered, self-contained capillary tube uses R290 hydrocarbon refrigerant
- Electronically commutated evaporator and condenser fan motors reduce energy consumption
- Fan motor reverses to blow dirt and dust away from the condensing coil
- Temperature holding range: 33-38 degrees F
- Refrigeration system is top mounted with evaporator positioned out of the food zone to maximize capacity
- Overall dimensions: 27 1⁄2 in. W x 39 1⁄8 in. D x 84 1⁄8 in. H
- 3.8 A, 1⁄4 HP
- 115 V/60 Hz/1 ph, 9-ft. cord with a NEMA 5-15P plug
*Image may not depict product color, inclusions or accessories.
*Free shipping on True Refrigeration STG1RPT-1G-1G-HC within the 48 contiguous states.
From The Manufacturer
True Refrigeration STG1RPT-1G-1G-HC Specifications
| Spec Attribute | Spec Value |
|---|---|
| Manufacturer | True Refrigeration |
| Compressor Location | Top |
| Cubic Feet | 25.3 |
| Depth (in) | 36.13 |
| Door Type | Glass |
| Doors | Full |
| Height (in) | 77.75 |
| Hertz | 60 |
| Hinge Configuration | Right |
| Interior Material | Aluminum |
| Kitchen Innovations Awards | 2015 |
| NEMA | 5-15P |
| No. of Doors | 2 |
| Phase | 1 |
| Product | Reach-In Refrigerators |
| Product Type | Commercial Refrigeration |
| Rating | Spec |
| Refrigerant | R290 (Hydrocarbon) |
| Sections | 1 |
| Series | Spec Series® |
| Special Features | Casters Included - Uninstalled |
| Type | Pass Thru |
| Voltage | 115 |
| Warranty | 7-year Parts & Labor; 7-year Compressor |
| Width (in) | 27.5 |
| Weight | 440.00 |
WARNING: Important Prop 65 information for California residents.
Compare to Similar Items
| Attributes |
True Refrigeration STG1RPT-1G-1G-HC True STG1RPT-1G-1G-HC 27 1/2" One Section Pass Thru Refrigerator, 2 Right Hinge Glass Doors, 115v Current Item |
Beverage-Air PRD1HC-1BG Beverage-Air PRD1HC-1BG 26" One Section Pass Thru Refrigerator, 2 Right Hinge Glass Doors, 115v |
|---|---|---|
| Customer Rating |
|
|
| Price | $8,551.96 / Each | $8,575.16 / Each |
| Shipping | Free Shipping | Free Shipping |
| Rating | Spec | Better |
| Cubic Feet | 25.3 | 22.9 |
| Width (in) | 27.5 | 26 |
| Doors | Full | Full |
| No. of Doors | 2 | 2 |
| Door Type | Glass | Glass |
| Type | Pass Thru | Pass Thru |
| Sections | 1 | 1 |
| Compressor Location | Top | Top |
| Depth (in) | 36.13 | 36.13 |
| Hinge Configuration | Right | Right |
| Refrigerant | R290 (Hydrocarbon) | R290 (Hydrocarbon) |
| Special Features | Casters Included - Uninstalled | |
| Height (in) | 77.75 | 84.13 |
| Series | Spec Series® | P-Series |
| Warranty | 7-year Parts & Labor; 7-year Compressor | 7-year Limited Parts & Labor; 7-year Compressor Parts |
- 5
- 4
- 3
- 2
- 1
Review this product!
It is a one-section pass-thru model with glass doors on both sides for double-sided access and visibility.
The refrigerator features bright LED lighting for energy-efficient interior illumination.
The cabinet offers approximately 25 cubic feet of refrigerated storage.
Three adjustable, PVC-coated wire shelves are included for flexible product arrangement.
The interior and exterior are stainless steel, ensuring durability and easy sanitation.
It has a self-contained, capillary tube refrigeration system using R290 refrigerant.
A digital temperature control with an external LED display provides accurate readings and adjustments.
Allow airflow space behind and above the cabinet for proper ventilation and condenser access.
The compressor is mounted at the top of the cabinet.
This unit measures 27 1⁄2 in. W x 36 1⁄8 in. D x 77 3⁄4 in. H.
Yes. The magnetic door gaskets are removable for cleaning or replacement.
Yes. It plugs into a standard outlet with a NEMA 5-15P plug.
This model has one full-height glass door on the front and one full-height glass door on the rear.
Yes. LED lighting brightens the cabinet interior.
This unit provides 25 cu. ft. of refrigerated storage in one section.
Yes. It comes with three adjustable PVC-coated wire shelves.
It has a stainless steel interior and exterior for durability and simplified cleaning.
It uses a self-contained capillary tube refrigeration system with R290 hydrocarbon refrigerant.
A digital temperature controller with an external LED display maintains and shows the cabinet temperature.
It has one section and two doors.
It maintains a holding temperature range from 33-38° F.
