Garland UN17FC78 78" Chef Base w/ (4) Drawers - 115v

Image may not depict product color, inclusions or accessories.

KaTom #: 451-UN17FC78 • MPN: UN17FC78
Ships Free

Extended Lead Time (14+ days)

(0 reviews)Write a Review
Price: $13,055.00
Login or call us for more info!

Image may not depict product color, inclusions or accessories.

Garland UN17FC78 Description


The Garland UN17FC78 freezer chef base is constructed from stainless steel, making the base durable and resistant to minor damage. Adjustable legs measure 6-inches tall and lift the base off of the countertop or other surface it sits on, which allows for more convenient cleaning. The compressor housing is on the right and has been tropicalized for an ambient temperature up to 100 degrees Fahrenheit. The stainless steel drawer slides are heavy duty. Magnetic door gaskets around the drawers help retain cold air. The handle on each drawer is flush with the rest of the drawer to help prevent damage. The Garland UN17FC78 freezer chef base can accommodate 12-inch-by-20-inch-by-4-inch hotel pans.

Product Details

  • Stainless steel construction is durable and resistant to minor damage
  • 6-in. adjustable legs lift the unit off of surfaces for easy cleaning under the base
  • Compressor housing on the right end of the unit
  • Santoprene magnetic door gasket helps retain cold air
  • Stainless steel drawer slides with stainless steel bearings
  • Flush-mounted handle is protected from damage
  • Scroll-type thermometer
  • Compressor has been tropicalized to 100 degrees F
  • Removable track assembly on the drawers
  • Uses R-404A refrigerant to maintain cool temperatures
  • Hot gas condensate evaporator is defrosted as needed to run properly
  • Drawers accommodate 12 in. x 20 in. 4 in. hotel pans
  • 115 V/60 Hz/1 ph, 13 HP, 1399 BTU, 16 A, NEMA 5-20P plug
  • Overall Dimensions: 78 in. L x 3234 in. W x 26316 in. H
  • cULus and UL listed; NSF certified

Polar Cuisine Freezer Base, self-contained refrigeration, 78" two-section, (2) 19" & (2) 27" drawers, stainless steel exterior, 6" stainless steel legs (available only when ordered with Cuisine Series modular cook tops) 115v/60/1-ph, 8.9 amps, (U S Range)

*The warranty will not be honored for residential or non-commercial use of any Commercial Equipment.

Warning Small Important Prop 65 information for California residents.

Garland UN17FC78 Specifications

PDF Spec Sheet
Manufacturer Garland
Depth (in) 33
Number of Drawers 4
Sections 2
Width (in) 78
Phase 1
Hertz 60
Voltage 115
Product Chef Base
Product Type Commercial Refrigeration
Weight 570.00
