Manitowoc Ice IDT0900W/SFA292 780 lb Full Cube Ice Machine w/ Ice Dispenser - 180 lb Storage, Bucket Fill, 208-230v/1ph

Designed with easyTouch® controls, the Manitowoc Ice IDT0900W-261/SFA292 ice maker and dispenser gives users control over production, enabling them to specify the hours the machine should run or how much ice it should make in a day. The amount it can make depends on the ambient air and water supply temperatures; if it's running continuously in ideal conditions, the unit produces 780 pounds of full-cube dice ice per day. These cubes are square and measure ⁷/₈ of an inch on all sides—great for cooling drinks, filling buckets, and bagging.

This Manitowoc Ice IDT0900W-261/SFA292 ice machine and dispenser provides convenient access to water and ice. Accommodating most containers, the dispensing area is large and features a lever with a rocking chute mechanism that reacts quickly to pressure. The drain pan contains any runaway ice or water overflow to keep the floors safe and dry. To resist corrosion and smudges, the metal exterior of the dispenser and ice machine is coated in DuraTech&trade, which resists corrosion hides fingerprints and other smudges. When the ice maker's internal components need to be cleaned, it alerts users with notifications on the easyTouch screen. Parts are accessible through the front, and some components—the curtain, water trough, and distribution tube—can be removed for cleaning.

Ice Maker Details

• Featured in the Indigo NXT™ series
• Makes dice ice
• 780-lb. maximum daily ice production
• 665-lb. AHRI-certified daily ice production
• Sensor probe measures ice to ensure consistent cube size
• Dice cube size: ⁷/₈ in. x ⁷/₈ in. x ⁷/₈ in.
• Corrosion-resistant DuraTech exterior
• easyTouch screen controls are icon based
• Programmable production enables operation at set times or until a daily quota is reached
• Alerts provide maintenance and cleaning recommendations
• Swing-out front panel enables quick foodzone access
• Removable curtain, water trough, distribution tube, and sensing probe
• AlphaSan® agent reduces the risk of bacterial growth
• Self-contained condenser
• Water-cooled compressor
• R410A refrigerant
• 12,700 average BTU; 14,800 peak BTU

Ice Dispenser Details

• 180-lb. ice capacity
• 1 water lever and 1 ice lever
• Large dispensing area fits buckets and containers
• Rocking chute dispense lever quickly responds when pressure is added or removed
• Drain pan captures overflow and contains messes
• Corrosion-resistant DuraTech exterior

Ideal Operating Conditions

• Clearances: 5 in. at back, 8 in. at top and sides
• Air temperature: 40-100 degrees F
• Water pressure: 20-80 PSI
• Water temperature: 40-90 degrees F

Dimensions & Utilities

• Ice Maker
• 30 in. W x 24¹/₂ in. D x 26¹/₂ in. H
• 8.8 A, 4.02 kW
• 208-230V/60 Hz/1 ph
• Ice Dispenser
• 30 in. W x 32 in. D x 60¹/₂ in. H
• 1.6 A
• 115 V/60 Hz/1 ph, 6-ft. cord with NEMA 5-15P plug
• Overall: 30 in. W x 32 in. D x 87 in. H

Product Features

*Free shipping on Manitowoc Ice IDT0900W/SFA292 within the 48 contiguous states.

From The Manufacturer

Indigo NXT™ Series Ice Maker w/ Ice Dispenser, cube-style, water-cooled, self-contained condenser, 30"W x 24-1/2"D x 26-1/2"H, production capacity up to 780 lb/24 hours at 70°/50° (665 lb AHRI certified at 90°/70°), DuraTech™ exterior, dice size cubes, R410A refrigerant, NSF, cULus; Vending Ice Dispenser with Built-In Water Valve, touchless lever, floor model, 30"W x 32"D x 82"H, AHRI certified 180-lb capacity, designed for dice or half-dice ice type, fills containers up to 11" high, stainless steel exterior with vinyl trim, accepts 22" or 30" dice or half-dice machines, cULus, CE, ADA compliant

*Image may not depict product color, inclusions or accessories.

Machine: 3-year Warranty, 5-year Compressor Parts; Dispenser: 3-year Parts & Labor
