American Range AR-24G-4B 48" 4 Burner Gas Range w/ Griddle & (2) Space Saver Ovens, Liquid Propane
Selected Gas Type: Liquid Propane

Ship times may vary due to supply chain constraints. Please contact our Sales Team if you need this item in a specified time frame.
Similar Products in Stock Now
American Range AR-24G-4B Description
This 48 inch American Range heavy duty restaurant range was designed for heavy and continuous usage. The all stainless steel exterior is durable and easy to clean. The stainless steel top shelf resists corrosion and provides extra storage in the kitchen. This liquid propane range features a removable stainless steel oven door for easy cleaning
Product Details
- Fully welded frame is sturdy and provides stability
- Porcelain oven interior provides easy clean up
- Pull off stainless steel door for easy cleaning
- 100% gas safety shut off
- Top shelf provides extra storage
- Matchless push button ignition to light standing pilot
- Stainless steel exterior is durable and easy to clean
- Adjustable thermostat from 150-500 degrees F
- 1 chrome plated rack per oven
- Overall Dimensions: 48-in. W x 28-1/2 in. D x 56-in. H
*Free shipping on American Range AR-24G-4B within the 48 contiguous states.
From The Manufacturer
Restaurant Range, gas, 48", (4) 32,000 BTU open burners, (1) 24" griddle, 1" thick plate, manual controls, (2) 20" space saver ovens, (2) racks per oven, stainless steel front, sides & high shelf, 6" chrome plated legs, 65.0kW, 222,000 BTU, cETLus, ETL-Sanitation, Made in USA
*Image may not depict product color, inclusions or accessories.

American Range AR-24G-4B Specifications
Spec Attribute | Spec Value |
---|---|
Manufacturer | American Range |
Additional Info | Contact Customer Service for altitudes above 2,000 feet |
Application | Heavy Duty |
Base | Space Saver Oven |
Total BTU | 222000 |
BTU / Burner | 32000 |
Controls | Manual |
Depth (in) | 32.25 |
Gas Type | LP |
Heat | Gas |
Height (in) | 56 |
Number of Ovens | Double |
Range Configuration | Burners/Griddle |
Warranty | 2-year Limited Parts & Labor |
Width (in) | 48 |
Plate Thickness (in) | 1 |
Burner Type(s) | Open |
Rating | Better |
Product | Gas Ranges |
Gas Inlet Size | 0.75 |
Product Type | Cooking Equipment |
Installation Type | Freestanding |
Burner Style | Grates |
Max Temp | 500 |
Number of Burners | 4 |
Griddle Location | Right |
Griddle Width (in) | 24 |
Vent | Backriser w/ hi-shelf |
Burner Configuration | Standard |
Open Burner BTU (ea) | 32000 |
Racks per Standard Oven | 2 |
Racks per Space Saver Oven | 2 |
Rack Positions per Space Saver Oven | 5 |
Space Saver Oven Dimensions | 20"W x 26-1/2"D x 13-1/2"H |
Space Saver Oven BTU/hr | 27000 |
Certifications | ETL |
Certifications | NSF |
Certifications | C ETL US Listed |
Certifications | ETL-Sanitation |
Weight | 620.00 |
