Southbend S60AA 60" 10 Burner Gas Range w/ (2) Convection Ovens, Natural Gas
$14,356.00 /Each
Call for details!
Selected Gas Type: Natural Gas
Ship times may vary due to supply chain constraints. Please contact our Sales Team if you need this item in a specified time frame.
Southbend S60AA Description
The Southbend S60AA NG S-series restaurant range is equipped with 10 open burners and two convection ovens. The burners generate 28,000 BTU and are cast-iron and non-clogging. Removable, cast-iron grate tops cover the burners. Two crumb drawers sit underneath the burners to catch messes and remove for easy cleaning. If the pilot light goes out, the flame failure safety device will shut off the flow of gas. The removable shelf, sides, and front are made from stainless steel to resist corrosion. At the front, there is a 4-inch rail that helps keep operators arms from being burnt and allows for cookware to sit there so cooks can easily plate food.
With two 35,000 BTU convection ovens, your demands for baked dishes will easily be met. The thermostat ranges from 175 to 550 degrees Fahrenheit. The burners are shaped like the letter U, evenly distributing heat throughout the cavity. Most of the oven is insulated with rock wool that is self-supporting. There are rack guides for the two removable racks that have five different positions. This unit has a 1⁄2 HP, 60 cycle, 1710 rpm permanent split phase motor to power each oven's convection fan. The Southbend S60AA NG S-series restaurant range is heated with natural gas.
- 2 removable racks with 5 guide positions
- Convection ovens are equipped with On/Off switches
- 60 cycle, 115 V, 1⁄2 HP, 1710 rpm permanent split phase motors power ovens' convection fans
- Self-supporting, block-type rock wool insulation in the four sides and top of ovens
- Flame failure safety device will cut off the gas flow is cut off if the pilot light goes out
- Oven burner is shaped like a “U” for even heat distribution
- 2 convection, 35,000 BTU ovens
- 22 1⁄2-in. flue riser with a single shelf
- Pressure regulator is factory installed
- Stainless steel, adjustable, 6-in. legs
- Spring doors with chrome handles on the ovens
- Lower valve panel is hinged and grants easy access to the gas valves
- Metal knobs each have a red stripe so operators can adjust burners easily
- 2 crumb drawers that sit under the burners easily remove for no-hassle cleaning
- 10 cast iron grate tops are removable
- 10 non-clog, cast iron, 28,000 BTU burners
- Removable shelf, front, and sides are stainless steel to resist corrosion
- 4-in. front rail is stainless steel and helps operators not get burned
- Oven interiors: 26 in. W x 24 in. D x 14 in. H
- Overall: 60 3⁄4 in. W x 41 3⁄4 in. D x 59 1⁄2 in. H
- Natural gas powered
- 115 V/60 Hz/1 ph, 5.9 A, 6-ft. cord with a 3-prong plug
*Image may not depict product color, inclusions or accessories.
*Free shipping on Southbend S60AA within the 48 contiguous states.
- Comparing Commercial Range Configurations
- Learn How to Choose the Right Commercial Range
- Base Options for Commercial Ranges
- What to Know Before Buying a Commercial Gas Range
- Cleaning Your Commercial Hood
- Gas vs Electric Ranges
- Natural Gas vs Propane
- Range Cleaning and Maintenance Tips
- What is a Commercial Range?
- Choosing the Right Range Configuration
- Commercial Range Repair and Troubleshooting
From The Manufacturer
S-Series Restaurant Range, natural gas, 60", (10) 28,000 BTU open burners, (2) convection ovens, snap action thermostat, removable cast iron grates, crumb drawer & shelf, hinged lower valve panel, includes (2) racks per oven, stainless steel front, sides, shelf, 4" front rail & 6" adjustable legs, 350,000 BTU, CSA, NSF
Southbend S60AA Specifications
| Spec Attribute | Spec Value |
|---|---|
| Manufacturer | Southbend |
| Additional Info | Contact Customer Service for altitudes above 2,000 feet |
| Application | Restaurant |
| Base | Convection Oven |
| BTU / Burner | 28000 |
| Burner Configuration | Standard |
| Burner Style | Grates |
| Burner Type(s) | Open |
| Controls | Manual |
| Convection Oven BTU/hr | 35000 |
| Convection Oven Dimensions | 26"W x 24"D x 14"H |
| Depth (in) | 34 |
| Gas Inlet Size | 0.75 |
| Gas Type | NG |
| Heat | Gas/Electric |
| Height (in) | 59.5 |
| Hertz | 60 |
| Installation Type | Freestanding |
| Max Temp | 550 |
| Number of Burners | 10 |
| Number of Ovens | Double |
| Open Burner BTU (ea) | 28000 |
| Phase | 1 |
| Product | Gas Ranges |
| Product Type | Cooking Equipment |
| Rack Positions per Convection Oven | 5 |
| Racks per Convection Oven | 2 |
| Range Configuration | Burners |
| Rating | Better |
| Series | S-Series |
| Total BTU | 350000 |
| Vent | Backriser w/ hi-shelf |
| Voltage | 115 |
| Warranty | 1-year Limited Parts & Labor |
| Width (in) | 60 |
| Weight | 1075.00 |
