Vulcan VCBB24B 24" Gas Range w/ Charbroiler & Storage Base, Liquid Propane

With the Vulcan VCBB24B V-series range, chefs can sear and grill proteins on its 24-inch-wide charbroiler and store ingredients and supplies in its cabinet base. To complement other pieces of back-of-house equipment, this 24-inch-wide by 36³⁄₄-inch-deep by 40³/₄-inch-tall piece's front, front top ledge, burner box, sides, base, and stub back are made of durable stainless steel, which resists corroding, denting, and scratching through daily use. The storage base is lined with universal rack guides to accommodate different sizes of food pans, and its removable shelf can store spices, condiments, cooking utensils, and other supplies. A stainless steel cabinet door encases the base to conceal stored contents. For stability during use, this unit is positioned on 6-inch legs that can be raised or lowered to level the unit on bumpy or sloped flooring.

To achieve a smoky grilled flavor, the Vulcan VCBB24B LP-gas-powered range is lined with heavy-duty cast iron grates that create appetizing grill lines. Because the grates are slanted, fat can drain from proteins, and flare-ups are less likely to occur. All four burners have individual pilot lights and controls so chefs can adjust each burner's heat as needed, and the char radiants absorb and direct heat toward the unit's top. For even heat distribution, the charbroiler is built with stainless steel supercharger burner dividers, and for thorough cleaning after use, staff can quickly remove the four grates.

Product Details

• Part of the V series
• 24-in.-wide charbroiler
• 4 burners with individual pilots and controls
• Stainless steel supercharger burner divider panels
• 4 heavy-duty, slanted cast iron grates
• Char radiants
• Stainless steel front, front top ledge, burner box, sides, base, and stub back
• 4-in. stub riser
• Cabinet base includes 1 removable shelf, universal rack guides, and stainless steel door
• Positioned on 6-in. adjustable legs
• 65,000 BTU

Dimensions & Utilities

• 24 in. W x 36³⁄₄ in. D x 40³/₄ in. H
• Powered by LP gas
• 1¹⁄₄-in. diameter front gas manifold
• ³⁄₄-in. rear gas connection

Product Features

*Free shipping on Vulcan VCBB24B within the 48 contiguous states.

From The Manufacturer

V Series Heavy Duty Range, gas, 24", charbroiler, cast iron grates and char-radiants, storage base, cabinet doors, stainless steel front, front top ledge, side, base, burner box & stub back, 6" adjustable legs, 65,000 BTU, CSA, NSF

*Image may not depict product color, inclusions or accessories.

1-year Limited Parts & Labor

Vulcan VCBB24B Specifications

Vulcan started producing equipment in Louisville Ky., more than 150 years ago. Today, the brand produces state-of-the-art cooking appliances, including fryers, ovens, and everything in between. The brand is owned by Illinois Tool Works, a global manufacturing leader.
