Vulcan started producing equipment in Louisville Ky., more than 150 years ago. Today, the brand produces state-of-the-art cooking appliances, including fryers, ovens, and everything in between. The brand is owned by Illinois Tool Works, a global manufacturing leader.
Vulcan V336HS 36" Gas Range w/ (3) Hot Tops & Standard Oven, Liquid Propane
Typically ships in 4 - 6 weeks
Free Shipping Item
$14,364.00 /Each
Low price guarantee - call us!
Selected Gas Type: Liquid Propane
Ship times may vary due to supply chain constraints. Please contact our Sales Team if you need this item in a specified time frame.
White Glove Delivery
Contact your sales rep for availability
Attention: Order by 06-01-2025 to save before the price increases!
Vulcan V336HS Description
Built with a standard oven base, the Vulcan V336HS gas range supports versatile cooking operations by combining baking functionality with a high-powered hot top surface. Fueled by liquid propane, this 36-inch-wide unit outputs a total of 140,000 BTU—90,000 of which is generated by three solid-top burners. Each hot top is crafted of heavy-duty cast iron to retain heat and distribute it evenly across the surface, making it suitable for simmering and holding large-volume cookware.
Stainless steel construction across the front, sides, base, burner box, and top ledge reinforces the Vulcan V336HS range against daily commercial use. Operators can adjust cooking zones individually using dedicated pilots and controls. A 3/4-inch ground steel griddle plate expands surface versatility, while a 4-inch stub riser helps shield walls from heat exposure. A 11⁄4-inch front gas manifold with a capped rear connection supports straightforward utility setup, and 6-inch adjustable stainless steel legs help level the unit on uneven floors.
Product Details
- Part of the V Series
- Made of stainless steel
- (3) 30,000 BTU hot top burners
- Heavy-duty cast iron hot top surfaces
- Includes 3/4-in. ground steel griddle plate
- Individual pilots and controls for each burner
- 11⁄4-in. front gas manifold and capped 11⁄4-in. rear gas connection
- 4-in. stainless steel stub riser
- 6-in. adjustable stainless steel legs
Standard Oven Base
- 50,000 BTU oven burner
- Temperature range: 150–550 degrees F
- Porcelain interior
- 1 oven rack adjustable to 3 positions
- Heavy-duty oven door with counterweight hinges
Dimensions & Utilities
- 36 in. W x 417⁄8 in. D x 401⁄2 in. H
- Powered by liquid propane
- Total BTU: 140,000
Product Features
*Free shipping on Vulcan V336HS within the 48 contiguous states.
From The Manufacturer
V Series Heavy Duty Range, gas, 36", (3) hot tops, standard oven, stainless steel front, front top ledge, sides, base, burner box & stub back, 6" adjustable legs, 140,000 BTU, CSA, NSF
*Image may not depict product color, inclusions or accessories.
1-year Limited Parts & Labor
Vulcan V336HS Specifications
| Spec Attribute | Spec Value |
|---|---|
| Manufacturer | Vulcan |
| Application | Heavy Duty |
| Base | Standard Oven |
| BTU / Burner | 30000 |
| Burner Configuration | Standard |
| Burner Style | None |
| Burner Type(s) | None |
| Depth (in) | 41.87 |
| Gas Type | LP |
| Heat | Gas |
| Height (in) | 40.5 |
| Installation Type | Freestanding |
| Number of Burners | None |
| Number of Ovens | Single |
| Product | Gas Ranges |
| Product Type | Cooking Equipment |
| Rack Positions per Standard Oven | 3 |
| Racks per Standard Oven | 1 |
| Range Configuration | Hot Top |
| Rating | Best |
| Series | V Series |
| Total BTU | 140000 |
| Vent | Stub Back |
| Warranty | 1-year Limited Parts & Labor |
| Width (in) | 36 |
| Weight | 615.00 |
Residential Users: This unit is not to be installed or operated in a residential or other non-commercial setting. Check local codes to ensure your foodservice kitchen is properly equipped for this piece. Use in an improper setting will void the warranty and the manufacturer will not provide parts or labor coverage for damage, failure, or other issues with the product. While this product may be covered by a manufacturer's warranty, vendor assumes no liability for product failure or any damages/injuries.
