Vulcan V2BG8TS 36" 2 Burner Gas Range w/ Griddle & Standard Oven, Liquid Propane

The Vulcan V2BG8TS commercial range is a 36-inch-wide by 36³⁄₄-inch-deep by 36-inch-tall unit comprised of two open-top burners, an 18-inch-wide griddle, and a standard oven, so multiple cooking tasks can be performed in a single footprint. To withstand high-volume use in demanding kitchens, its front, front top ledge, sides, base, and stub back are made of durable rust-, corrosion-, and wear-resistant stainless steel. Because it's positioned on adjustable 6-inch stainless steel legs, it can be raised or lowered as needed on irregular flooring to reduce the chance of the unit rocking or wobbling during use.

The top section is divided in half; a griddle is located on the right and two burners are on the left. The griddle's ground-steel ³⁄₄-inch-thick plate is durable enough to withstand high-volume heating, and it retains heat to reduce recovery time after use. So staff can set the griddle to a specific temperature, it features snap-action thermostatic controls. The two open burners have separate pilot lights and controls, enabling staff to modify burner heat to achieve different results. While the rear cast grate measures 14 inches by 17 inches to accommodate pans and pots, the 11-inch by 17-inch front cast grate can support small- or medium-sized cookware. After use, these grates can be lifted off to perform thorough cleaning.

The Vulcan V2BG8TS LP-gas-powered range's standard oven base features a 27-inch-wide by 27-inch-deep by 13-inch-tall interior cavity and comes with one oven rack that can be adjusted to one of three rack positions. Operators can access the interior by opening the heavy-duty counterweight door. To achieve optimal broiling, roasting, baking, or reheating results, its temperature can be set from 150 to 550 degrees Fahrenheit. Because its bottom, sides, and interior door panel are made of porcelain, this oven is easy to clean.

Range Details

• Part of the V series
• Stainless steel front, front top ledge, sides, base, and stub back
• 2 open-top burners with lift-off heads
• Separate burner pilots and controls
• Heavy-duty lift-off cast grates
• 11-in. x 17-in. front grate
• 14-in. x 17-in. rear grate
• Extra-deep stainless steel crumb tray
• 18-in.-wide griddle with ³⁄₄-in.-thick ground-steel plate
• Snap-action thermostatic controls enable precise adjustment
• 6-in. adjustable stainless steel legs

Oven Details

• Operating temperature: 150-550 degrees F
• Simple-to-clean porcelain base, sides, and interior door panel
• Includes 1 rack adjustable to 3 positions
• Heavy-duty oven door with counterweight hinges
• 50,000 BTU

Dimensions & Utilities

• Oven interior: 27 in. W x 27 in. D x 13 in. H
• Overall: 36 in. W x 36³⁄₄ in. D x 36 in. H
• Powered by LP gas
• 1¹⁄₄-in. diameter front gas manifold
• 1¹⁄₄-in. rear gas connection
• 150,000 BTU

Product Features

From The Manufacturer

V Series Heavy Duty Range, gas, 36", (2) 35,000 BTU open burners, (1) 18" griddle. thermostatic controls, standard oven, stainless steel front, front top ledge, sides, base, burner box & stub back, 6" adjustable legs, 150,000 BTU, CSA Flame, CSA Star, NSF

*Image may not depict product color, inclusions or accessories.

1-year Limited Parts & Labor
