Traulsen G10002P 29 7/8" One Section Pass Thru Refrigerator, (4) Right Hinge Solid Doors, 115v

Temperature—displayed in Fahrenheit or Celsius—in the Traulsen G10002P one-section pass-thru refrigerator can be set on a level between 34 and 38 degrees Fahrenheit by using the digital microprocessor controller. R290 refrigerant is metered by a thermostatic expansion valve based on temperature. This system is ideal for high-demand applications where the doors are opened often.

Doors on the front and back of the refrigerator create a pass-thru design, often used to connect the kitchen to serving areas. These doors are half the size of standard full doors—reducing cold air loss when one is opened—and self-close to retain cold air, while staying open at 120 degrees so operators can stock the cabinet. Gaskets in the doors seal them to the frame to minimize cold air leaks. These gaskets are designed to resist damage from chemical cleaners, showing dirt so users know when to clean them.

Inside the Traulsen G10002P pass-thru refrigerator, three wire shelves hold stored items. Because the shelves are epoxy-coated, they resist corrosion and increase the cabinet's durability. Clockwise airflow evenly distributes cold air, and to prevent users from overloading the interior, guards at the side walls keep product out of the airflow path. Interior lighting provides visibility so users can see the stored items. Made completely of metal, the unit is durable to support heavy use and mounted on 6-inch casters that lock in place when necessary.

Product Details

• 24.72-cu.-ft. interior space
• 3 epoxy-coated steel wire shelves
• Load-Sure Guard creates cabinet space for air to flow between the side wall and stored items
• LED lights illuminate the cabinet to increase product visibility
• Heavy-duty stainless steel exterior front with anodized aluminum sides
• Anodized aluminum interior resists corrosion and scratches
• 2-in.-thick, high-density polyurethane insulation is foamed in place to retain cold air
• Locking, 6-in. casters
• 1,650 BTU

Product Features

Self-contained Refrigeration System

• Temperature holding range: 34-38 degrees F
• Microprocessor controller
• 3-digit LED temperature display in Fahrenheit or Celsius
• R290 refrigerant
• Thermostatic expansion valve meters refrigerant sent to the evaporator coil based on the temperature
• Top-mounted placement separates the components from floor dirt and debris
• Components are behind the front-mounted, 1-piece louver to provide service accessibility
• Front-facing condenser coil is clearly accessible for cleaning

Pass-thru Door Design

• Right-hinged, stainless steel doors on the front and back create a pass-thru design to connect front of the house with the back
• Self-closing doors reduce cold air loss and heat gain
• Doors stay open at 120 degrees for product stocking and cabinet cleaning
• Long-lasting EZ Clean door gaskets
• Heaters behind the door openings eliminate condensation

Dimensions & Utilities

• 29⁷⁄₈ in. W x 38⁷⁄₈ in. D x 83⁷⁄₁₆ in. H
• 4.9 A, 2.47 kWh/day, ¹⁄₅ HP
• 115 V/60 Hz/1 ph, 9-ft. cord with a NEMA 5-15P plug

*Free shipping on Traulsen G10002P within the 48 contiguous states.

From The Manufacturer

Dealer's Choice Refrigerator, Pass-thru, one-section, 24.7 cu. ft., self-contained refrigeration, control side: (2) half-height solid doors (hinged right), other side: (2) half-height solid doors (hinged right), (3) epoxy coated shelves (factory installed), microprocessor control with LED display, LED interior lights, stainless steel doors and louver rail, anodized aluminum sides & interior, 6" high casters, R290 Hydrocarbon refrigerant, 1/4 HP, 115v/60/1, 3.8 amps, NEMA 5-15P,cETLus, ETL-Sanitation, ENERGY STAR®

*Image may not depict product color, inclusions or accessories.

6-year Parts & Labor; 7-year Compressor

Traulsen G10002P Specifications

Documents

Spec Sheet

Warranty

Use & Care Guide

Manual

Brochure
