MODEL N8873 - N8800 Series, Drop-In Single-Tank Electric Hot Food Wells, Hot Food Well Unit, 5 Pan Size
Product Shown Model N8887
Good, Basic, Cold Storage
- Top shall be one-piece 18-gauge stainless steel, with .60' (1.524 cm) overhang around perimeter. Well shall be 8.00' (20.3 cm) deep, creased to a 1.00' male N.P.T. stainless steel drain. Unit shall be provided with adapter bars to allow placement of 12' x 20' (30.5 cm x 50.8 cm) pans. Unit shall have the same number of 1000 watt heating elements as the unit's 12' x 20' pan capacity, mounted on underside of well. Sides shall be insulated with 1.00' (2.5 cm) fiberglass; bottom shall have 2.00' (5.1 cm) blanket insulation. Exterior housing shall be 20-gauge galvanized steel.
- Unit shall have a single thermostat wired to a control panel for mounting in counter or at a remote location; 2' (0.6 m) length of wiring and conduit are provided. Unit shall have a three wire electrical junction box to allow hard-wiring at installation.
Options & Accessories
- Adapter plates and bars
- Single- or double-service flip-up sneeze guards
- Telescoping covers
Photo May Include Optional Accessories!
Drop-In Hot Food Well Unit, Electric, single tank, wet type with drain, 5-pan size for 12" x 20" pans, remote control panel with single thermostat control, stainless steel top & wells, galvanized outer liner, (72-3/8" x 25" cutout required), cUL, UL, NSF, 208-230v/60/1ph
*The warranty will not be honored for residential or non-commercial use of any Commercial Equipment.
Delfield N8873 SpecificationsPDF Spec Sheet
