Delfield N8873 Drop In Hot Food Well w/ (5) Full Size Pan Capacity, 208 230v/1ph

Image may not depict product color, inclusions or accessories.

KaTom #: 032-N8873 • MPN: N8873
Ships Free

Extended Lead Time (14+ days)

(0 reviews)Write a Review
Price: $2,225.00
Login or call us for more info!

Image may not depict product color, inclusions or accessories.

Delfield N8873 Description


MODEL N8873 - N8800 Series, Drop-In Single-Tank Electric Hot Food Wells, Hot Food Well Unit, 5 Pan Size

Product Shown Model N8887

Good, Basic, Cold Storage

Standard Features

  • Top shall be one-piece 18-gauge stainless steel, with .60' (1.524 cm) overhang around perimeter. Well shall be 8.00' (20.3 cm) deep, creased to a 1.00' male N.P.T. stainless steel drain. Unit shall be provided with adapter bars to allow placement of 12' x 20' (30.5 cm x 50.8 cm) pans. Unit shall have the same number of 1000 watt heating elements as the unit's 12' x 20' pan capacity, mounted on underside of well. Sides shall be insulated with 1.00' (2.5 cm) fiberglass; bottom shall have 2.00' (5.1 cm) blanket insulation. Exterior housing shall be 20-gauge galvanized steel.
  • Unit shall have a single thermostat wired to a control panel for mounting in counter or at a remote location; 2' (0.6 m) length of wiring and conduit are provided. Unit shall have a three wire electrical junction box to allow hard-wiring at installation.

Options & Accessories

  • Adapter plates and bars
  • Single- or double-service flip-up sneeze guards
  • Telescoping covers

Photo May Include Optional Accessories!

Drop-In Hot Food Well Unit, Electric, single tank, wet type with drain, 5-pan size for 12" x 20" pans, remote control panel with single thermostat control, stainless steel top & wells, galvanized outer liner, (72-3/8" x 25" cutout required), cUL, UL, NSF, 208-230v/60/1ph

*The warranty will not be honored for residential or non-commercial use of any Commercial Equipment.

Warning Small Important Prop 65 information for California residents.

Delfield N8873 Specifications

PDF Spec Sheet
Manufacturer Delfield
Warranty 1 year limited parts & labor
Capacity (Pans) 5
Controls Thermostatic
Type Hot
Pan Size Full
Specialty Options With Drain
Voltage 208/230
Phase 1
Hertz 60
Product Hot Food Well
Product Type Food Bars & Buffets
Weight 200.00
Delfield N8873 Certifications
  • UL
  • NSF
