True STG1DT-2HS-HC 27 1/2" SPEC SERIES® One Section Commercial Combo Refrigerator Freezer - Solid Doors, Dual Temp, 115

The True STG1DT-2HS-HC one-section refrigerator freezer has six wire shelves with an epoxy coating that resists corrosion, while LED lighting enhances visibility so operators can find the ingredients they need. Constructed of aluminum and stainless steel, the unit is strong and corrosion resistant. Its doors are hinged on the left with durable handles on the right, and they can self-close or stay open past 120 degrees for loading and unloading.

This True STG1DT-2HS-HC one-section refrigerator freezer has one independently operating, self-contained refrigeration system for each section. These systems are top mounted to prevent floor debris from getting sucked in, and the refrigerator operates between 33 and 38 degrees Fahrenheit, while the freezer maintains a temperature of -10 degrees Fahrenheit. Each section has an external digital temperature display, and since the freezer's evaporator gets extremely cold, its defrost system removes frost that forms from condensation buildup. These defrost cycles begin on a timer and end when the evaporator temperature is low enough for optimal operation.

Best used when combined with routine preventative maintenance, the fan motor reverses for 20 seconds after the compressor is turned on. It's a self-cleaning feature, designed to blow off excess dust and debris from the condensing coil. A clean coil ensures the unit operates using less energy and more efficiency.

Product Details

• Top refrigerator section with a freezer section on the bottom
• 3 wire shelves coated in PVC per section
• LED lighting illuminates the interior
• Aluminum interior walls, back, and exterior side walls
• Interior floor and ceiling constructed of durable stainless steel
• Stainless steel, left-hinged doors self-close to prevent cold air loss
• Doors stay open at 120 degrees
• 1-piece magnetic door gaskets seal in cold air and can be removed without tools
• Foamed-in-place polyurethane insulation prevents cold air from seeping out
• 5-in. castors
• Part of the Spec Series®

Refrigeration Systems

• Each section equipped with independently operating, self-contained refrigeration systems
• Electrically commutated evaporator and condenser fan motors efficiently move a consistent volume of air than other systems to produce less heat
• Removes dust from the condensing coil using a reverse condensing fan motor
• Top-mounted systems will not suck in debris from the floor
• Freezer uses a time-initiated, temperature-terminated defrost system
• R134A refrigerant
• Freezer operating temperature: -10 degrees F
• Refrigerator temperature range: 33-38 degrees F
• 2 exterior digital temperature displays

Dimensions & Utilities

• 27¹⁄₂ in. W x 35¹⁄₄ in. D x 84¹⁄₈ in. H
• 6.4 A, ¹⁄₁₀ refrigerator HP, ¹⁄₃ freezer HP
• 115 V/60 Hz/1 ph, 9-ft. cord with a NEMA 5-15P plug

*Free shipping on True Refrigeration STG1DT-2HS-HC within the 48 contiguous states.

From The Manufacturer

SPEC SERIES® Refrigerator/Freezer, reach-in, one-section, (2) stainless steel half doors, locks, cam-lift hinges, digital temperature control, (3) gray shelves, LED interior lights, stainless steel front, aluminum sides, aluminum interior, 5" castors, R290 Hydrocarbon refrigerant, R 1/10HP, F 1/4HP, 115v/60/1-ph, 3.7 amps, NEMA 5-15P, cULus, UL EPH Classified, ENERGY STAR®

*Not as Shown - Left Hinge

7-year Parts & Labor; 7-year Compressor
