Hoshizaki PT1A-HS-HS Steelheart 27 1/2" One Section Pass Thru Refrigerator - (4) Right Hinge Solid Doors, 115v
$8,350.00 /Each
Contact us for details!
Hoshizaki PT1A-HS-HS Description
The Hoshizaki PT1A-HS-HS pass-thru refrigerator has a total holding capacity of 24.2 cubic feet, giving users lots of space to store ingredients or finished products. Users can arrange products on three wire shelves held up by stainless steel supports. This pass-thru refrigerator enables users to conserve energy—it has half doors to limit cold air loss when it's opened.
The Hoshizaki PT1A-HS-HS single-section refrigerator produces cold air with a self-contained refrigeration system. This condenser uses R290 refrigerant, which is an eco-friendly hydrocarbon. To ensure a long lifespan through extensive use, the system's evaporator coils are coated with epoxy.
- Part of the Steelheart series
- 24.2-cu.-ft. capacity
- Holding temperature range: 31-52 degrees F
- 1 pass-thru section
- Solid, self-closing Dutch doors are made of stainless steel
- Flush-mount door handle is made of extruded aluminum
- Door opening direction can be reversed in the field
- Top-mounted refrigeration system is self-contained
- Evaporator coils are epoxy coated for corrosion resistance
- Thermal expansion valve system
- Solid-state digital controller
- Temperature alarms
- Front, top, interior, and sides are made of stainless steel
- Interior LED light helps users see products
- LED display
- Stainless steel shelf supports with 3 adjustable, epoxy-coated wire shelves
- Mounted on 4-in. casters for mobility; 2 casters brake
- 348-BTU heat transfer capacity
- Ideal ambient temperature range: 45-100 degrees F
- 27.5 in. W x 35.75 in. D x 79.5 in. H
- 5 A, 1.31 kW, 1⁄4 HP
- 115 V/60 Hz/1 ph, 10-ft. cord with NEMA 5-15P plug
*Nominal cubic footage measurements sometimes provided by refrigeration manufacturers may not indicate actual usable space. If you require a specific capacity, please call one of our customer care representatives to ensure the unit you order meets your needs.
*Image may not depict product color, inclusions or accessories.
*Free shipping on Hoshizaki PT1A-HS-HS within the 48 contiguous states.
From The Manufacturer
Steelheart Refrigerator, 24.2 cu ft, pass-thru, one section, half stainless steel doors, top mount refrigeration, stainless steel interior, front, sides, and top, interior LED light, R290 hydrocarbon refrigerant, solid state digital controller, temperature alarms, LED display, self-closing doors, extruded aluminum flush-mount door handle, field reversible doors, epoxy-coated evaporator coils, expansion valve, stainless steel shelf supports, (3) epoxy coated wire shelves, 4" casters, 10 ft cord and plug, 27.5"W x 35.75"D x 79.5"H, 5 amps, 115v/60/1ph, NSF
Watch a video about this product
Hoshizaki PT1A-HS-HS Specifications
| Spec Attribute | Spec Value |
|---|---|
| Manufacturer | Hoshizaki |
| Color | Silver |
| Compressor Location | Top |
| Cubic Feet | 24.2 |
| Depth (in) | 35.75 |
| Door Type | Solid |
| Doors | Half |
| Evaporator Type | Expansion Valve |
| Height (in) | 79.5 |
| Hertz | 60 |
| Hinge Configuration | Right |
| Interior Material | Stainless Steel |
| NEMA | 5-15P |
| No. of Doors | 4 |
| Number of Shelves | 3 |
| Phase | 1 |
| Product | Reach-In Refrigerators |
| Product Type | Commercial Refrigeration |
| Rating | Best |
| Refrigerant | R290 (Hydrocarbon) |
| Sections | 1 |
| Series | Steelheart Series |
| Special Features | Casters Included - Uninstalled |
| Supports | Casters |
| Thermometer Type | Digital |
| Type | Pass Thru |
| Voltage | 115 |
| Warranty | 7-year Parts & Labor; 7-Year Compressor |
| Width (in) | 27.5 |
| Weight | 357.00 |
