Traulsen G26014P 52" Two Section Pass Thru Refrigerator, (2) Glass Doors, (2) Solid Doors, 115v

The Traulsen G26014P two-section commercial refrigerator's cabinet comes with six wire shelves; they are epoxy coated for corrosion resistance and promote uniform airflow. LED lighting is used in the cabinet to increase visibility so users can quickly find what they need. Doors are integrated into the front and back of this unit, creating a pass-thru design for the kitchen and serving areas. The unit's control side has full-height solid doors that retain cold air, while the other side has full-height glass doors that provide product visibility. All the doors self-close, but at 120 degrees, they stay open for convenient product stocking. Each door has an all-metal door handle and durable, easy-to-clean gasket.

The refrigeration system in this Traulsen G26014P pass-thru two-section refrigerator operates with a thermostatic expansion valve—an alternative to capillary tubes that provides more accurate, efficient refrigerant metering to the evaporator. Refrigerant helps maintain the cool temperatures, which can be set to run between 34 and 38 degrees Fahrenheit. The microprocessor controller ensures adjusting the temperature is straightforward, and the LED display shows the readings in Celsius or Fahrenheit.

Product Details

• 49.75-cu.-ft. interior space
• 6 epoxy-coated steel wire shelves
• Load-Sure Guard ensures air can flow properly without product obstructing its path
• LED lighting brightens the interior, promoting product visibility
• Foamed-in-place, 2-in.-thick polyurethane insulation
• Heavy-duty stainless steel exterior front
• Anodized aluminum exterior sides
• Corrosion-resistant anodized aluminum interior
• (4) 6-in. locking casters
• 4,610 BTU
• Requires 12-in. clearance above the refrigerator

Pass-thru Doors

• Control side has full-height solid doors
• Opposite side has full-height glass doors
• Left hinged on left side and right hinged on right side
• Self-closing for cold-air retention
• 120-degree, stay-open design for product loading
• EZ Clean gaskets are designed for lasting durability
• All-metal handle on each door

Refrigeration System

• Top mounted to separate the components from dirt and dust on the floor
• Uses R290 refrigerant
• Thermostatic expansion valve maintains the set temperature level by metering refrigerant to the evaporator with accuracy
• Large, high-humidity evaporator is placed outside the food zone, maximizing cabinet storage space
• Front-facing condenser coil is accessible for regular cleaning
• Temperature holding range: 34-38 degrees F
• Microprocessor controls
• 3-digit LED display for the temperature in Fahrenheit or Celsius

Dimensions & Utilities

• 52¹⁄₈ in. W x 37¹⁵⁄₁₆ in. D x 83⁷⁄₁₆ in. H
• 9.6 A, 5.54 kW, ³⁄₄ HP
• 115 V/60 Hz/1 ph, 9-ft. cord with a NEMA 5-15P plug

*Free shipping on Traulsen G26014P within the 48 contiguous states.

From The Manufacturer

Dealer's Choice Refrigerator, Pass-thru, two-section, 49.75 cu. ft., top mounted self-contained refrigeration, control side: (2) full-height solid doors (left/right hinged), other side: (2) full-height glass doors (left/right hinged), stainless steel front, anodized aluminum sides & interior, (3) epoxy coated shelves per section per section (factory installed), microprocessor control with LED display, LED interior lights, 6" high casters, R-290 Hydrocarbon refrigerant, 3/4 HP, 115v/60/1, 7.9 amps, NEMA 5-15P, cETLus, ETL-Sanitation, ENERGY STAR®

*Image may not depict product color, inclusions or accessories.

6-year Parts & Labor; 7-year Compressor
