Traulsen G10004P 29 7/8 One Section Pass Thru Refrigerator, (4) Left Hinge Solid Doors, 115v

Write a Review!KaTom #: 206-G10004P • MPN: G10004P
  • 206-G10004P Primary Thumbnail Image
  • 206-G10004P Multiple Thumbnail Image #1
  • 206-G10004P Multiple Thumbnail Image #2

Typically ships in 2 - 3 weeks

Free Shipping Item

$7,220.12 /Each

Contact us for details!

Ship times may vary due to supply chain constraints. Please contact our Sales Team if you need this item in a specified time frame.

Traulsen G10004P Description

The Traulsen G10004P pass-thru refrigerator has a self-contained, top-mounted system. With this placement, it does not operate near dust and debris on the floor. The components are accessible behind the one-piece louver assembly, and the condenser coil has a front-facing design for additional cleaning access. The temperature is adjustable using the microprocessor controller, which has a range between 34 and 38 degrees Fahrenheit. For correct temperatures, the thermostatic expansion valve meters R-450A refrigerant based on the setting.

Front and back doors feature a pass-thru design. This design enables establishments to connect back-of-the-house kitchens with front-of-the-house serving areas. All doors are solid and use a half-size design to retain more cold air than full doors. The doors are self-closing, although they stay open at 120 degrees to facilitate product restock.

The cabinet comes with three epoxy-coated steel shelves with a wire design that enables even air circulation throughout the interior. Guards in the walls prevent items from being stored too close to the wall, inhibiting airflow. Because the unit is made of anodized aluminum and stainless steel, it resists corrosion, dents, and scratches. The Traulsen G10004P one-section pass-thru refrigerator is mounted on 6-inch casters that can be locked in place when needed.

Product Details

  • 24.72-cu.-ft. interior space
  • 3 steel wire shelves are coated in epoxy for corrosion resistance
  • Load-Sure Guard on the cabinet's side walls protects the airflow pattern by preventing stored items from blocking it
  • LED interior lighting ensures stored items are visible
  • Exterior has a stainless steel front and anodized aluminum sides
  • Interior is made of anodized aluminum
  • Foamed-in-place, 2-in.-thick, high-density polyurethane insulation retains cold air
  • Locking, 6-in. casters
  • 1,650 BTU

Self-contained Refrigeration System

  • Temperature holding range: 34-38 degrees F
  • Microprocessor temperature controller with a 3-digit LED display that can be set to show in Fahrenheit or Celsius
  • Uses non-flammable R-450A refrigerant
  • Thermostatic expansion valve maintains the temperature by metering refrigerant sent to the evaporator coil
  • Mounted on top of the cabinet to reduce contact with floor dirt and dust
  • 1-piece louver assembly provides access to the components
  • Condenser coil has a front-facing design to facilitate cleaning

Pass-thru Door Design

  • Front and back both have 2 left-hinged, stainless steel half doors for a convenient pass-thru design
  • Self-closing doors stay open at a 120-degree angle to ensure convenient product stocking
  • Lasting EZ Clean door gaskets
  • Built-in door heaters reduce condensation buildup

Dimensions & Utilities

  • 2978 in. W x 3878 in. D x 83716 in. H
  • 4.9 A, 2.47 kW, 15 HP
  • 115 V/60 Hz/1 ph, 9-ft. cord with a NEMA 5-15P plug
Note: Nominal cubic footage measurements sometimes provided by refrigeration manufacturers may not indicate actual usable space. If you require a specific capacity, please call one of our customer care representatives to ensure the unit you order meets your needs.

From The Manufacturer

Dealer's Choice Refrigerator, Pass-thru, one-section, 24.7 cu. ft., self-contained refrigeration, control side: (2) half-height solid doors (hinged left), other side: (2) half-height solid doors (hinged left), (3) epoxy coated shelves (factory installed), microprocessor control with LED display, LED interior lights, stainless steel doors and louver rail, anodized aluminum sides & interior, 6" high casters, R290 Hydrocarbon refrigerant, 1/4 HP, 115v/60/1, 3.8 amps, NEMA 5-15P, cETLus, ETL-Sanitation, ENERGY STAR®

*Image may not depict product color, inclusions or accessories.

Additional Product Information

Cord Attached

This product includes a cord and plug

Natural Refrigerant

Product made with Hydrocarbon Refrigerants

Warranty Icon
6-year Parts & Labor; 7-year Compressor

Traulsen G10004P Specifications

Certifications
This product has met the minimum standards for food safety as set by the ETL.
This product is made in the USA.
This product has been certified by the NSF (National Safety Foundation), as meeting international...
Product tested and deemed compliant to the U.S. and Canadian product safety standards
Residential Users: The warranty will not be honored for residential or non-commercial use of any Commercial Equipment.

Warning Small Important Prop 65 information for California residents.
