Traulsen G10003P 29 7/8" One Section Pass Thru Refrigerator, 4 Right Hinge Solid Doors, 115v
$8,208.00 /Each
Attention: Order by 12-01-2026 to save before the price increases!
Traulsen G10003P Description
The Traulsen G10003P one-section pass-thru refrigerator has an anodized aluminum interior, stainless steel exterior front, and stainless steel exterior sides. This all-metal construction makes the unit more durable than units with plastic components. It comes with three shelves in the cabinet and a guard to prevent users from affecting airflow by storing items too close to the walls.
Solid, stainless steel doors on the front and back of the cabinet provide interior access. This pass-thru design encourages users to place the refrigerator between the front and back of the house to ensure product flows conveniently to the serving area. Each door is half the size of a full door to separate the unit into sections that reduce the amount of air that flows in and out. The doors have a self-closing design, except at 120 degrees, where they stay open so users can load product.
Operators can set the temperature in this Traulsen G10003P pass-thru refrigerator to suit their application. The microprocessor controller has a temperature range between 34 and 38 degrees Fahrenheit and uses an LED display to show the interior temperature. The refrigeration components in the unit are top mounted to separate them from dirt, dust, and debris on the floor. It uses R290 refrigerant for eco-friendly cooling. A thermostatic expansion valve meters refrigerant to the evaporator coil to maintain the right temperature in the cabinet.
- 24.72-cu.-ft. interior space
- 3 epoxy-coated steel wire shelves
- Load-Sure Guard on the interior side walls prevents users from storing items too close and disrupting air circulation
- LED cabinet lights brighten stored items
- Stainless steel exterior front with anodized aluminum sides
- Anodized aluminum interior
- 2-in.-thick, foamed-in-place, high-density polyurethane insulation
- Locking, 6-in. casters
- 1,650 BTU
- Temperature holding range: 34-38 degrees F
- Microprocessor control
- 3-digit LED temperature display can display Fahrenheit or Celsius
- R290 hydrocarbon refrigerant
- Thermostatic expansion valve meters refrigerant sent to the evaporator coil based on the cabinet temperature
- Top-mounted placement removes components from dust and dirt on the floor
- 1-piece louver can be removed for component access
- Condenser coil faces the front for cleaning accessibility
- Right-hinged, stainless steel front half doors
- Left-hinged, stainless steel rear doors
- Self-closing design prevents cold air from escaping quickly
- Doors stay open at a 120-degree angle for cabinet stocking
- Durable EZ Clean door gaskets
- Heaters are integrated behind the door openings to eliminate condensate
- 29 7⁄8 in. W x 38 7⁄8 in. D x 83 7⁄16 in. H
- 4.9 A, 2.47 kW, 1⁄5 HP
- 115 V/60 Hz/1 ph, 9-ft. cord with a NEMA 5-15P plug
*Nominal cubic footage measurements sometimes provided by refrigeration manufacturers may not indicate actual usable space. If you require a specific capacity, please call one of our customer care representatives to ensure the unit you order meets your needs.
*Image may not depict product color, inclusions or accessories.
*Free shipping on Traulsen G10003P within the 48 contiguous states.
From The Manufacturer
Traulsen G10003P Specifications
| Spec Attribute | Spec Value |
|---|---|
| Manufacturer | Traulsen |
| Additional Info | Contact Customer Service for Additional Information |
| Color | Silver |
| Compressor Location | Top |
| Cubic Feet | 24.72 |
| Depth (in) | 37.94 |
| Door Type | Solid |
| Doors | Half |
| Evaporator Type | Expansion Valve |
| Height (in) | 83.44 |
| Hertz | 60 |
| Hinge Configuration | Right |
| Interior Material | Aluminum |
| NEMA | 5-15P |
| No. of Doors | 4 |
| Number of Shelves | 3 |
| Phase | 1 |
| Product | Reach-In Refrigerators |
| Product Type | Commercial Refrigeration |
| Rating | Better |
| Refrigerant | R290 (Hydrocarbon) |
| Sections | 1 |
| Series | Dealer's Choice |
| Special Features | Casters Included - Uninstalled |
| Supports | Casters |
| Thermometer Type | Digital |
| Type | Pass Thru |
| Voltage | 115 |
| Warranty | 6-year Parts & Labor; 7-year Compressor |
| Width (in) | 29.88 |
| Weight | 365.00 |
Important Prop 65 information for California residents.
- 5
- 4
- 3
- 2
- 1
Review this product!
This unit provides 24.72 cu. ft. of refrigerated storage in one section.
Yes. The half-height door design lets staff open a smaller portion of the cabinet during loading and retrieval.
The compressor is mounted at the top of the cabinet.
This unit measures 29 7⁄8 in. W x 37 15⁄16 in. D x 83 7⁄16 in. H.
This model has half-height solid doors.
Yes. It plugs into a standard outlet with a NEMA 5-15P plug.
It uses R290 hydrocarbon refrigerant.
Yes. Casters are included for repositioning or cleaning access.
This reach-in fits restaurants, hotels, schools, and healthcare kitchens where staff access refrigerated ingredients throughout service.
It has one section and four doors.
It comes with three shelves for organizing refrigerated items.
It maintains a holding temperature range from 34-38° F.
