Ice-O-Matic ICE1506HR49 30 3/8" ICE Series™ Half Cube Ice Machine Head - 1450 lb/24 hr, Remote Cooled, 208-230v/1ph
$8,304.00 /Each
Selected Compressor Type: Remote Cooled
Selected Ice Type: Half Cube
Ice-O-Matic ICE1506HR49 Description
Producing as much as 1,432 pounds of half-cube ice per day in optimal conditions, the Ice-O-Matic ICE1506HR49 ice machine head is excellent for locations that serve a large volume of iced beverages such as soda and tea. Half-cube ice from this ice maker is large enough to effectively chill drinks without quickly watering them down, yet small enough to nestle tightly together in the beverage container for improved product displacement. Measuring just 30 inches wide, this ice machine head fits well into cramped floorplans where space is at a premium. To guard against corrosion, the unit's evaporator plates are nickel plated.
The Ice-O-Matic ICE1506HR49 half cube ice machine head is made of durable stainless steel that resists dents, scratches, and rust from heavy use. It operates with a remote condenser, meaning this ice maker head can produce a large amount of ice in an area adjacent to the dining room while exhausting heat and noise in a remote location, creating minimal disturbance. Because the unit is air-cooled, it consumes less water than a water-cooled ice machine. Enhanced with an antimicrobial agent, this ice maker resists the spread of germs.
- ICE® series
- Air cooled
- Produces half-size cube ice
- Ice cube dimensions: 3⁄8 in. W x 7⁄8 in. D x 7⁄8 in. H
- 1,432-lb. maximum daily ice production
- Functions with remote condenser
- 30-in. width saves space in small areas
- Corrosion-resistant stainless steel construction adds durability
- Harvest Assist function increases capacity and consistency
- PURE ICE® antimicrobial protection is built in
- Nickel-plated evaporator plates resist corrosion
- Ice level and ice deflector
- Ideal ambient air temperature: 50-100 degrees F
- Ideal incoming water temperature: 40-100 degrees F
- Ideal incoming water pressure: 20-60 PSI
- Heat displacement: 22,491 BTU
- 30 2⁄5 in W x 26 3⁄10 in. D x 22 3⁄100 in. H
- Potable water inlet: 3⁄8 in.
- Water outlet: 3⁄4 in.
- 24.5 A, 4.76 kW
- 230 V/60 Hz/1 ph
*Image may not depict product color, inclusions or accessories.
*Free shipping on Ice-O-Matic ICE1506HR49 within the 48 contiguous states.
From The Manufacturer
Ice-O-Matic ICE1506HR49 Specifications
| Spec Attribute | Spec Value |
|---|---|
| Manufacturer | Ice-O-Matic |
| 24 Hr. Production (lb) | 1450 |
| Also Known As | ICE1506HR |
| Compressor Type | Remote Cooled |
| Depth (in) | 26.3 |
| Height (in) | 22.03 |
| Ice Type | Half Cube |
| Phase | 1 |
| Product | Ice Machine Heads |
| Product Type | Ice Makers & Bins |
| Rating | Better |
| Refrigerant | R449A |
| Series | ICE Series™ |
| Suggested Use | Commercial |
| Voltage | 208/230 |
| Warranty | 3-year Parts & Labor; 5-year Evaporator & Compressor Parts |
| Water Inlet (in) | 0.38 |
| Width (in) | 30.4 |
| Weight | 300.00 |
- 5
- 4
- 3
- 2
- 1
Review this product!
It can produce up to 1,450 lb. of ice per 24 hours.
It makes half-cube ice.
It measures 30 3/8 in. W x 26 5/16 in. D x 22 in. H.
It uses a remote-cooled condensing system.
It requires 208/230 V electrical service.
It uses single-phase power.
It uses R449A refrigerant.
It requires a hardwired electrical connection.
Its listed certifications include cULus Listed and NSF.
Its exterior is made of stainless steel.
It requires a 3/8-in. water inlet connection.
No, this ice machine head is sold without an ice bin.
Yes, it requires a separate remote condenser.
