Ice-O-Matic CIM0836GA90/KSI-1 30 1/4" Elevation Series™ Extra-Large Cube Ice Machine Head - 850 lb/24 hr, Air Cooled, 208-230v/1ph
$7,160.00 /Each
Ice-O-Matic CIM0836GA90/KSI-1 Description
Because it produces gourmet, grande-size ice cubes, the Ice-O-Matic CIM0836GA90/KSI-1 ice machine head is suitable for serving premium drinks and high-end liquors in an upscale restaurant or bar. These ice cubes measure 1 1⁄4 inches by 1 1⁄8 inches by 7⁄8 inches, and in ideal operating conditions, this unit can produce 850 pounds of this ice per day. If environmental temperatures are too high, it makes closer to 645 pounds per day. Its refrigeration system is air cooled and self-contained to expedite installation.
The Ice-O-Matic CIM0836GA90/KSI-1 large-cube ice machine head has dishwasher-safe food zone components to streamline cleaning. These pieces are made of plastic, and they include no crevices that could harbor debris. To inhibit the formation of bacteria, the unit is protected with built-in PURE ICE® antimicrobial and a SafeIce UV light. Cleaning can be performed with the push of a button, and an LED status display alerts users when maintenance is needed.
- Part of the Elevation Series™
- SafeIce UV light sanitizes interior components
- Self-contained, air-cooled refrigeration system
- 850-lb. maximum daily ice production
- 645-lb. AHRI-certified daily ice production
- Makes grande-size cubes
- Uses R290 refrigerant
- Grande-size cube dimensions: 1 1⁄4 in. x 1 1⁄8 in. x 7⁄8 in.
- Food zone components are dishmachine safe
- Exhausts from the side and top
- Plastic food zone
- PURE ICE antimicrobial slows bacterial formation
- LED display indicates when cleaning is required
- Single-touch cleaning
- Ideal ambient air temperature: 50-100 degrees F
- Ideal incoming water temperature: 40-100 degrees F
- Ideal incoming water pressure: 20-80 PSIG
- 18,200-BTU heat transfer capacity
- Must be paired with an ice bin or dispenser (sold separately)
- Ice maker: 30 1⁄4 in. W x 24 1⁄4 in. D x 26 9⁄10 in. H
- 13.90 A, 5.40 kW
- 208-230 V/60 Hz/1 ph
*Image may not depict product color, inclusions or accessories.
*Free shipping on Ice-O-Matic CIM0836GA90/KSI-1 within the 48 contiguous states.
From The Manufacturer
Elevation Series™ Modular Cube Ice Maker w/ SafeIce Upgrade Kit, air-cooled, self-contained condenser, dual exhaust top/side air discharge, 30" W, approximately 850 lb production/24 hours at 70°/50° (693 lb at 90°/70°), grande size cubes, LED status display, one touch sanitize/descaling controls, dishwasher safe food zone components, R290 refrigerant, cULus, cUL Energy Verified
Ice-O-Matic CIM0836GA90/KSI-1 Specifications
| Spec Attribute | Spec Value |
|---|---|
| Manufacturer | Ice-O-Matic |
| 24 Hr. Production (lb) | 850 |
| Also Known As | CIM0836GA |
| Compressor Type | Air Cooled |
| Depth (in) | 24.25 |
| Height (in) | 26.9 |
| Ice Type | Extra-large Cube |
| Phase | 1 |
| Product | Ice Machine Heads |
| Product Type | Ice Makers & Bins |
| Rating | Better |
| Refrigerant | R290 (Hydrocarbon) |
| Series | Elevation Series™ |
| Suggested Use | Commercial |
| Voltage | 208/230 |
| Warranty | 3-year Parts & Labor; 5-year Evaporator & Compressor Parts |
| Water Inlet (in) | 0.38 |
| Width (in) | 30.25 |
| Weight | 230.00 |
