Scotsman FS0822AX-1/B530S/KBT27 800 lb Prodigy Plus® Flake Ice Machine w/ Bin & Filter - 536 lb Storage, Air Cooled, 115v
Typically ships in 1 - 3 Business Days
Retail Price: $19,809.00
$7,894.00 /Each
Scotsman FS0822AX-1/B530S/KBT27 Description
This Scotsman FS0822AX-1/B530S/KBT27/AP2-P flake ice machine head is air cooled and comes with a B530S bin to store prepared ice and keep it chilled until needed. Flake-style ice is most suitable for packing into ice packs at healthcare facilities, blending into smoothies and other frozen drinks, and keeping seafood and produce displays chilled. Operating with sealed bearings, a stainless steel auger and evaporator, and integrated indicator lights, the ice maker can perform for extended time periods with minimal maintenance. Its exterior is made of stainless steel, enhancing the unit's resistance to dents, scratches, and rust.
Designed to fit well with the FS0822AX-1/B530S/KBT27/AP2-P ice machine head, this Scotsman B530S storage bin includes a KBT27 bin top that eliminates gaps and conserves cold air when installing a 22-inch-wide ice maker on top of this 30-inch-wide bin. It has a metallic finish exterior and rests on 6-inch-tall legs, raising the bin to a comfortable height for repeated scooping. Its door opens from the front and is top hinged. With a total capacity of 536 pounds of prepared flake ice, the bin insulates lots of product so it's ready to serve to meet periods of increased demand. This ice machine comes standard with the AP2-P water filter.
- Prodigy Plus®
- Air cooled
- Produces flake ice
- Useful for grocery stores and seafood shops
- 800-lb. maximum daily ice production
- 641-lb. AHRI-certified daily ice production
- Self-contained condenser saves space
- No side clearance required with front-breathing design
- Sealed bearings deliver extended performance
- AutoAlert™ indicator lights signal users when maintenance is needed
- AgION™ antimicrobial enhancement
- Unit-specific QR code for simple use
- Front-accessible air filter is removable
- Durable auger and evaporator made of stainless steel for long-term use
- Simple, 1-touch cleaning reduces employee labor
- Stainless steel finish
- Cools with R290 refrigerant
- AP2-P water filter included
- Ideal ambient air temperature: 50-100 degrees F
- Ideal incoming water temperature: 40-100 degrees F
- Ideal incoming water pressure: 20-80 PSI
- Heat displacement: 7,100 BTU
- Comes with KBT27 bin top for use with 22-in. flakers
- Front-opening, top-hinged door
- Storage capacity: 536 lbs.
- 30-in. width fits in tight spaces
- Metallic exterior finish
- Baffle can be removed without tools
- Polyurethane insulation
- Polyethylene liner
- 6-in. legs
- Head: 22 in. W x 24 in. D x 23 in. H
- Bin: 30 in. W x 34 in. D x 44 in. H
- 16 A
- 115 V/60 Hz/1 ph
*Image may not depict product color, inclusions or accessories.
*Free shipping on Scotsman FS0822AX-1/B530S/KBT27 within the 48 contiguous states.
From The Manufacturer
Prodigy Plus® Ice Maker, flake style, air-cooled, self-contained condenser, production capacity up to 800 lb/24 hours at 70°/50° (606 lb AHRI certified at 90°/70°), sealed maintenance-free bearings, AutoAlert™ indicating lights, unit specific QR code, front facing removable air filter, stainless steel evaporator and auger, one-touch cleaning, stainless steel finish, AgION™ antimicrobial protection, R290 refrigerant, 115v/60/1-ph, NSF, cULus
Ice Bin, top-hinged front-opening door, 536 lb application capacity, for top-mounted ice maker, 30" width, metallic finish exterior, toolless removable baffle, polyurethane insulation, polyethylene liner, includes 6" legs, NSF; (KBT27) Bin Top, for use with all 22" cubers, flakers & nugget makers (except EH222) on B230, B330 & B530 bins
AquaPatrol™ Plus Water Filtration System, double system, 4.2 gallons per minute max flow, designed for cubers over 650 lb and up to 1,200 lb, and for flakers and nuggets over 1,200 lb, cULus, NSF
Scotsman FS0822AX-1/B530S/KBT27 Specifications
| Spec Attribute | Spec Value |
|---|---|
| Manufacturer | Scotsman |
| 24 Hr. Production (lb) | 800 |
| Access | Lift Up Door |
| Also Known As | FS0822A-1/B530S/KBT27 |
| Bin Capacity (lb) | 536 |
| Compressor Type | Air Cooled |
| Depth (in) | 34 |
| Height (in) | 73 |
| Hertz | 60 |
| Ice Type | Flake |
| Includes | AP2-P Filtration |
| Phase | 1 |
| Product | Ice Machines with Bins |
| Product Type | Ice Makers & Bins |
| Rating | Best |
| Refrigerant | R290 (Hydrocarbon) |
| Series | Prodigy Plus® |
| Special Features | AgION™ Antimicrobial Protection |
| Special Features | Inline Water Filter Included |
| Special Features | Sealed, Maintenance-Free Bearings |
| Suggested Use | Commercial |
| Voltage | 115 |
| Warranty | Commercial: 3-year Parts & Labor; 5-year Compressor Parts; Residential: 1-year Parts & Labor |
| Water Inlet (in) | 0.38 |
| Width (in) | 30 |
| Weight | 333.00 |
