Southbend DC-3S Direct Steam Pressure Steamer w/ (12) Full Size Pan Capacity, 115v/1ph
$29,200.50 /Each
Call for details!
Southbend DC-3S Description
The Southbend DC-3S direct steam pressure steamer has three compartments within a 36-inch cabinet base, providing independent automatic timer controls for precise operation. Each compartment features universal pan supports, and optional sliding shelves can accommodate two full-size gastronorm pans. The stainless steel construction enhances durability and a removable shelf support system facilitates cleaning. The doors open 180 degrees and latch securely with a wheel-and-screw mechanism.
Southbend's DC-3S direct steam pressure steamer is designed for a maximum operating pressure of 6 psi, providing consistent cooking performance. The control housing, also constructed of stainless steel, includes a full-access removable panel. At the end of a cooking cycle, the system automatically shuts off, exhausts steam, and drains condensate while triggering an audible signal.
Mounted on a full-perimeter angle-frame cabinet base, this unit is equipped with thermostatically controlled cold water to condense steam before releasing it into the drain. It stands on six-inch stainless steel legs with adjustable front bullet feet and flanged rear feet for secure floor mounting.
- Stainless steel construction
- Three-compartment design with independent automatic timer controls
- Universal pan supports with optional sliding shelves
- Doors open 180 degrees and latch securely
- Removable shelf supports
- Thermostatically controlled steam exhaust system
- Full-perimeter angle-frame cabinet base
- Control housing with full-access removable panel
- Six-inch stainless steel legs with adjustable bullet feet (front) and flanged feet (rear)
- Overall dimensions: 36 in. W x 33 7⁄8 in. D x 68 in. H
- Maximum operating pressure: 6 psi
- 115 V/60 Hz/1 ph
*Image may not depict product color, inclusions or accessories.
*Free shipping on Southbend DC-3S within the 48 contiguous states.
From The Manufacturer
Steamer, direct steam, pressure-type, (3) compartments, 36" cabinet base, independent automatic timer controls with visible and audible signals, automatic shut-off, 304 stainless steel construction, (4) stainless steel legs with adjustable flanged feet, 115v/60/1ph hardwire for controls, cCSAus, NSF
Southbend DC-3S Specifications
| Spec Attribute | Spec Value |
|---|---|
| Manufacturer | Southbend |
| Also Known As | Crown DC-3 |
| Amps | 8 |
| Application | High Volume |
| Base | Cabinet |
| Controls | Manual |
| Depth (in) | 33.88 |
| Heat | Direct Steam |
| Height (in) | 68 |
| Hertz | 60 |
| No. of Compartments | 3 |
| Pan Capacity | 12 |
| Pan Type | Full Size Steam Pans |
| Phase | 1 |
| Product | Steamers |
| Product Type | Cooking Equipment |
| Special Features | 6" Adjustable Legs |
| Special Features | Automatic Timer |
| Steam Generator | External Source |
| Steamer Type | Pressure |
| Style | Floor |
| Voltage | 115 |
| Warranty | 1-year Parts & Labor |
| Water Source | Plumbed |
| Width (in) | 36 |
| Weight | 815.00 |
