Structural Concepts GHS456R (CURVED) 51" Fusion® Full Service Bakery Case w/ Curved Glass, 110-120v
$17,675.00 /Each
Login or call us for your price
Structural Concepts GHS456R (CURVED) Description
The Structural Concepts GHS456R Fusion® horizontal open air cooler provides full-service merchandising in compact layouts, combining a curved lift-up front glass with four vertical display levels. This 51-inch model operates with a Breeze self-contained refrigeration system that uses R290 hydrocarbon refrigerant and maintains product temperatures at or below 40 degrees Fahrenheit. Its front-breathing design eliminates the need for rear clearance and improves flexibility during installation. Rear sliding glass doors enhance service access, while frosted LED lighting and solid shelving support a clean, high-visibility product presentation.
Constructed for repeated use in service areas, the Structural Concepts GHS456R Fusion® cooler features a stainless steel rear exterior and a black powder-coated interior to balance durability with visual contrast. The rail-mounted base enables leveling with shims, ensuring stable placement on uneven flooring. Frosted LED lighting across the top and shelving improves product visibility from all angles, supporting impulse sales and efficient customer interaction.
- Fusion Series
- Horizontal unit
- 4 display levels
- Stainless steel rear exterior
- Black powder-coated interior
- Stainless steel end panels with mirror interior
- Curved lift-up front glass
- Clear glass rear sliding doors
- 1-in. Boston bumper
- Frosted LED 3500K lighting at top and shelves
- Casters w/ levelers
- Self-contained Breeze refrigeration system
- Front-breathing design
- R290 hydrocarbon refrigerant
- Average product temperature: 40 degrees F or less
- Shelf: 48 in. W x 20 in. D (each level)
- Interior: 48 in. W x 27 in. D x 30 in. H
- Overall: 51 in. W x 43 in. D x 55 3⁄4 in. H
- 15.91 A, 1,516 W
- 110–120 V/60 Hz/1 ph, 6-ft. cord with NEMA 5-20P or L5-20P plug
*Nominal cubic footage measurements sometimes provided by refrigeration manufacturers may not indicate actual usable space. If you require a specific capacity, please call one of our customer care representatives to ensure the unit you order meets your needs.
*Image may not depict product color, inclusions or accessories.
*Free shipping on Structural Concepts GHS456R (CURVED) within the 48 contiguous states.
From The Manufacturer
Fusion® Refrigerated Full Service Case with Lift-up Curved Front Glass, 51"W x 43"D x 55-3/4"H, 40°F or less integrated average product temperature, LED top and shelf lights with frosted lens, Sliding rear doors, Breeze self-contained R290 refrigeration, stainless steel rear exterior, cETLus, ETL-Sanitation
Watch a video about this product
Structural Concepts GHS456R (CURVED) Specifications
| Spec Attribute | Spec Value |
|---|---|
| Manufacturer | Structural Concepts |
| Access | Full Service |
| Color | Black |
| Compressor Type | Self Contained |
| Depth (in) | 43 |
| Design | Curved |
| Design | Horizontal |
| Door Type | Sliding |
| Height (in) | 55.75 |
| Hertz | 60 |
| NEMA | 5-20P |
| NEMA | L5-20P |
| Number of Levels | 4 |
| Phase | 1 |
| Product | Bakery Display Cases |
| Product Type | Commercial Refrigeration |
| Rating | Best |
| Refrigerant | R290 (Hydrocarbon) |
| Refrigeration Type | Refrigerated |
| Series | Fusion® |
| Shelving Type | Solid |
| Special Features | Black Interior |
| Special Features | Casters Included - Installed |
| Special Features | Curved Glass |
| Special Features | LED Lighting |
| Voltage | 110/120 |
| Warranty | 1-year Limited Parts & Labor; 5-year Compressor |
| Width (in) | 51 |
| Weight | 875.00 |
