Hoshizaki KM-161BAJ 23 3/4"W Crescent Cube Undercounter Ice Machine - 163 lbs/day, Air Cooled, ADA
IN STOCK: Ships in 1 Business Day
5+ in Stock
$3,320.00 /Each
Contact us for details!
Selected Compressor Type: Air Cooled
Hoshizaki KM-161BAJ Description
Featuring EverCheck™ technology, the Hoshizaki KM-161BAJ undercounter ice maker informs operators of system malfunctions quickly. With a simple on and off switch, this unit can be controlled without removing the panel. Its stainless steel exterior can be wiped clean, and its slide-in door supports quick content access. As many as 78 pounds of ice can be stored in the bin for peak business hours.
In ideal situations, the Hoshizaki KM-161BAJ undercounter ice maker produces as much as 163 pounds of crescent ice per day. In the self-contained condenser, air flows in and out the front, and its filter is removable for cleaning. The H-GUARD Plus Antimicrobial protects the ice scoop from bacteria buildup for clean ice.
- 163-lb. maximum daily ice production
- 123-lb. AHRI-certified daily ice production
- 78-lb. storage capacity
- Stainless steel exterior for durability
- EverCheck technology alerts users of system malfunctions
- Produces crescent cubes measuring 1 1⁄2 in. x 1 1⁄8 in. x 1⁄2 in.
- Front-breathing, self-contained condenser
- Condenser is air cooled with components that can be serviced quickly
- Slide-in door for full access
- Power switch operation
- Runs with R134A refrigerant
- Corrosion-resistant stainless steel evaporator
- CycleSaver™ design makes a lot of ice each cycle
- 6-in. legs
- Ideal water temperature: 45-90 degrees F
- Ideal ambient air temperature: 45-100 degrees F
- 3,050-BTU heat transfer capacity
- ADA compliant
- 23.82 in. W x 28.43 in. D x 39 in. H
- 7.1 A, 8.60 kW
- 115 V/60 Hz/1 ph, 6.5-ft. cord with a NEMA 5-15P plug
*Image may not depict product color, inclusions or accessories.
*Free shipping on Hoshizaki KM-161BAJ within the 48 contiguous states.
From The Manufacturer
Ice Maker With Bin, Cube-Style, 23-3/4"W, air-cooled, self-contained condenser, production capacity up to 163 lb/24 hours at 70°/50° (123 lb AHRI certified at 90°/70°), 78 lb. built-in ice storage capacity, crescent style cube, front opening bin, stainless steel exterior, 6" painted legs, 115v/60/1-ph, 7.1 amps, NSF, UL, cETLus, ADA Compliant
Hoshizaki KM-161BAJ Specifications
| Spec Attribute | Spec Value |
|---|---|
| Manufacturer | Hoshizaki |
| 24 Hr. Production (lb) | 163 |
| Bin Capacity (lb) | 78 |
| Compressor Type | Air Cooled |
| Depth (in) | 28 |
| Design | ADA Height |
| Drain Type | Gravity |
| Front Style | Lift Door |
| Height (in) | 39 |
| Hertz | 60 |
| Ice Type | Crescent Cube |
| NEMA | 5-15P |
| Phase | 1 |
| Product | Undercounter Ice Machines |
| Product Type | Ice Makers & Bins |
| Rating | Best |
| Refrigerant | R134a |
| Series | KM Series |
| Special Features | Alert System |
| Special Features | Antimicrobial |
| Special Features | Removable Air Filter |
| Suggested Use | Commercial |
| Voltage | 115 |
| Warranty | 3-year Parts & Labor; 5-year Parts & Labor Evaporator; 5-year Compressor & Condenser Parts |
| Water Inlet (in) | 0.5 |
| Width (in) | 23.75 |
| Weight | 161.00 |
Important Prop 65 information for California residents.
- Hoshizaki KM160BAJ
Compare to Similar Items
| Attributes |
Hoshizaki KM-161BAJ Hoshizaki KM-161BAJ 23 3/4"W Crescent Cube Undercounter Ice Machine - 163 lbs/day, Air Cooled, ADA Current Item |
||
|---|---|---|---|
| Customer Rating |
|
|
|
| Price | $3,320.00 / Each | $1,679.00 / Each | $1,679.00 / Each |
| Shipping | Free Shipping | Free Shipping | Free Shipping |
| Lead Time | IN STOCK: Ships in 1 Business Day | QUICK SHIP: Typically ships in 1 - 3 Business Days | QUICK SHIP: Typically ships in 1 - 3 Business Days |
| Ice Type | Crescent Cube | Full Cube | Half Cube |
| 24 Hr. Production (lb) | 163 | 165 | 165 |
| Bin Capacity (lb) | 78 | 89 | 89 |
| Width (in) | 23.75 | 26 | 26 |
| Compressor Type | Air Cooled | Air Cooled | Air Cooled |
| Drain Type | Gravity | Gravity | Gravity |
| Rating | Best | Better | Better |
| Special Features | Alert System | Removable Air Filter | Removable Air Filter |
| Series | KM Series | PKU | PKU |
| Suggested Use | Commercial | Commercial | Commercial |
| Front Style | Lift Door | Lift Door | Lift Door |
| Depth (in) | 28 | 26.5 | 26.5 |
| Height (in) | 39 | 38.5 | 38.5 |
| Design | ADA Height | Standard Height | Standard Height |
| Refrigerant | R134a | R404A | R404A |
| Voltage | 115 | 115 | 115 |
| Warranty | 3-year Parts & Labor; 5-year Parts & Labor Evaporator; 5-year Compressor & Condenser Parts | 1-year Parts & Labor | 1-year Parts & Labor |
