Howard-McCray R-CMS40E-12-LED 148-1/2" Full Service Red Meat Case w/ Straight Glass - (1) Level, 115v

Designed to operate in an environment of 75 degrees Fahrenheit, the Howard McCray R-CMS40E-12-LED full-service red meat case includes an air-insulated baffle to prevent water from dripping into the food display. Ideal for red meat, this unit comes with thermal-insulated front glass and two rows of LED lights for visibility. Because the refrigeration system is designed for remote installation, it does not add heat and noise to the area.

The system includes an upper humidity coil and copevap system, eliminating the need for a condensate pan. Food must be cooled before being placed inside, as this stainless steel Howard McCray R-CMS40E-12-LED red meat case is intended to keep products cold, not cool them on its own. The rear compression jamb on the double-pane doors prevents air leaks, reducing energy costs. This unit is available in 4-, 6-, 8-, 10-, and 12-foot lengths, and in white, black, and stainless steel; please contact customer care to specify a different model.

Product Details

• Temperature holding range: 34-36 degrees F
• R448A refrigerant and expansion valve system
• Copevap design eliminates the need for condensate pan
• Humidity coil inside the top
• Remote refrigeration system is sold separately
• Electronically controlled automatic defrost
• Stainless steel construction
• White exterior and interior
• Baffle prevents moisture from dripping into the display
• (2) ¹⁄₄-in.-thick, removable end panels for continuous lineup
• Rear and front grilles are removable for access to internal components
• Front bumper reduces the risk of dents
• Double-pane, removable doors
• Rear compression door jamb
• 2 rows of LED lighting
• Thermal-insulated front glass shows the contents while retaining cold air
• Includes drain
• 4,200 BTU

Dimensions & Utilities

• 148.5 in. W x 40 in. D x 53 in. H
• 2.4 A
• 115 V/60 Hz/1 ph

*Free shipping on Howard-McCray R-CMS40E-12-LED within the 48 contiguous states.

From The Manufacturer

One level only; additional shelf optional

Red Meat Service Case, 148-1/2"W, single duty, endless design, full length gravity coil system, extra full length humidity coil at the main deck, stainless steel top, white exterior & white interior, designed for remote refrigeration, R448A expansion valve included, remote condensing units & other hook ups are not included, 115v/60/1-ph, 2.4 amps, 4200 BTU

*Image may not depict product color, inclusions or accessories.

1-year Parts & Labor
