Pitco SSH75-3FD Gas Fryer - (3) 75 lb Vats, Floor Model, NG

KaTom #: 169-SSH753FDNG • MPN: SSH75-3FD NG
  • 169-SSH753FDNG Primary Thumbnail Image
  • 169-SSH753FDNG Multiple Thumbnail Image #1
  • 169-SSH753FDNG Multiple Thumbnail Image #2
Free Shipping Item

$54,523.00 /Each

Call for details!

Selected Gas Type: Natural Gas

Liquid PropaneLiquid Propane
Jamie Schwerin User Image
Ask a Foodservice Equipment Specialist

Pitco SSH75-3FD Description

The Pitco SSH75-3FD gas fryer, part of the Solstice Supreme™ series, is designed for high-volume frying with (3) 75-pound full tanks, providing a total oil capacity of 225 pounds. The integrated Solstice™ Filter Drawer System simplifies oil management by removing debris and extending oil life, while the easy two-step filtering process allows operators to maintain oil quality with minimal effort. A matchless ignition system automatically lights the pilot when powered on, reducing the need for manual relighting. Solid-state controls include a melt cycle and boil-out mode to assist with fryer cleaning, helping to maintain efficiency in commercial kitchens.

Designed with efficiency in mind, the Pitco SSH75-3FD gas fryer features a self-cleaning burner system that minimizes carbon buildup, reducing maintenance and ensuring long-term reliability. The under-fryer drawer filtration system includes an 8-gallon-per-minute pump for quick oil refilling, keeping downtime to a minimum. An extra-large 3-inch curved drain spout swivels for convenient oil disposal, reducing splashing and enhancing operator safety. The stainless steel tank, front, and sides provide durability and corrosion resistance in demanding kitchen environments. A tube rack directs crumbs and debris into a cool zone to prevent burning and preserve oil quality, while a removable basket hanger enables tool-free maintenance. Adjustable 10-inch legs provide stability on uneven surfaces and allow easy access for cleaning.

  • Solstice Supreme series
  • Floor model
  • Prepackaged fryer system with Solstice Filter Drawer System
  • 3 frypots: 75-lb. oil capacity per tank
  • 225 lb. total oil capacity
  • Stainless steel tank, front, and sides
  • Patented Solstice Burner Technology without blower or ceramics
  • Self-cleaning burner with downdraft protection
  • Solid-state controls with melt cycle and boil-out mode
  • Matchless ignition with DVI drain valve interlock
  • High-temperature safety limit switch
  • 1-1⁄4-in. full port drain valve
  • Integrated flue deflector
  • 10-in. adjustable legs
  • Tube rack
  • Removable basket hanger

  • Under-fryer drawer filtration system
  • Easy two-step filtering process
  • 8-gpm filter pump
  • Self-aligning filter connection
  • Rear oil return
  • 3-in. curved drain spout
  • Stainless steel filter pan with rear wheels
  • Self-storing filter pan lid

  • Frying area: 18-in. W x 18-in. D per frypot
  • Cook depth: 3 1⁄4 - 5-in.
  • Powered by natural gas
  • 105,000 BTU per frypot (total 315,000 BTU)
  • 36.6 kW

*Image may not depict product color, inclusions or accessories.

*Free shipping on Pitco SSH75-3FD within the 48 contiguous states.

Additional Product Information

Additional Product Information

From The Manufacturer

Solstice Supreme™ High Efficiency Prepackaged Fryer System with Solstice™ Filter Drawer System, natural gas, (3) 75 lb. oil capacity full tanks, solid state controls, boil out & melt cycle, drain valve interlock, matchless ignition, self-clean burner, downdraft protection, stainless steel tank, front & sides, under-fryer drawer filtration, total 315,000 BTU (-FFF), ENERGY STAR®, CSA Flame, CSA Star, NSF, CE

Warranty Icon
1-year Limited Parts & Labor

Watch a video about this product

Pitco SSH75-3FD Specifications

Documents
Residential Users: This unit is not to be installed or operated in a residential or other non-commercial setting. Check local codes to ensure your foodservice kitchen is properly equipped for this piece. Use in an improper setting will void the warranty and the manufacturer will not provide parts or labor coverage for damage, failure, or other issues with the product. While this product may be covered by a manufacturer's warranty, vendor assumes no liability for product failure or any damages/injuries.
