Summit BIM63OSADA 14 3/4"W Top Hat Undercounter Ice Machine - 68 lbs/day, Air Cooled, ADA
QUICK SHIP: Typically ships in 1 - 3 Business Days
Retail Price: $3,140.00
$2,103.80 /Each
Summit BIM63OSADA Description
The Summit BIM63OSADA undercounter ice machine features a 14 3⁄4-inch width and an undercounter configuration designed for built-in or freestanding installation in indoor and outdoor settings. Its stainless steel cabinet supports use in exposed environments, while the panel-ready reversible door enables integration with surrounding cabinetry. Designed to produce clear top hat ice, the unit creates a distinctive shape suited for beverage service, and an included scoop supports convenient ice retrieval. Adjustable leveling legs help stabilize the unit during installation.
Producing up to 68 pounds of ice per day, the Summit BIM63OSADA ice machine stores as much as 26 pounds in its internal bin for steady access. Touch controls provide user operation, while an automatic defrost system helps maintain performance. The built-in pump supports flexible drainage options, and the sealed back design contributes to a streamlined setup. Air-cooled operation works with R600a hydrocarbon refrigerant to support ice production, while the unit’s layout accommodates consistent use across residential and commercial applications.
- 68-lb. daily ice production
- 26-lb. bin storage capacity
- Top hat clear ice production
- Built-in or freestanding installation
- Indoor and outdoor compatible design
- Panel-ready reversible door
- Touch controls
- Built-in pump for drainage
- 4 leveling legs
- Stainless steel cabinet
- Sealed back design
- Ice scoop included
- Uses R600a hydrocarbon refrigerant
- Air-cooled compressor system
- Automatic defrost operation
- 14 3⁄4 in. W x 24 3⁄4 in. D x 32 in. H
- 6 A
- 115 V/60 Hz/1 ph, cord with a NEMA 5-15P plug
*Image may not depict product color, inclusions or accessories.
From The Manufacturer
Watch a video about this product
Summit BIM63OSADA Specifications
| Spec Attribute | Spec Value |
|---|---|
| Manufacturer | Summit |
| 24 Hr. Production (lb) | 68 |
| Bin Capacity (lb) | 26 |
| Compressor Type | Air Cooled |
| Depth (in) | 24.75 |
| Design | ADA Height |
| Drain Type | Pump |
| Front Style | Stainless Door |
| Height (in) | 32 |
| Hertz | 60 |
| Ice Type | Top Hat |
| NEMA | 5-15P |
| Phase | 1 |
| Product | Undercounter Ice Machines |
| Product Type | Ice Makers & Bins |
| Rating | Good |
| Refrigerant | R600a (Hydrocarbon) |
| Special Features | Adjustable Leveling Feet |
| Special Features | Digital Controls |
| Special Features | Field Reversible Door |
| Special Features | Outdoor Rated |
| Suggested Use | Commercial |
| Suggested Use | Home/Office |
| Suggested Use | Outdoor |
| Voltage | 115 |
| Warranty | 1-year Limited Parts & Labor; 5-year Compressor Parts |
| Water Inlet (in) | 0.25 |
| Width (in) | 14.75 |
| Weight | 68.00 |
