Beverage-Air BB48HC-PT-S 48" Pass Thru Bar Refrigerator - 4 Swinging Solid Doors, Stainless, 115v
$6,819.00 /Each
Call for details!
Selected Color: Stainless Steel
Beverage-Air BB48HC-PT-S Description
Built for busy counters where staff serve from both sides, the Beverage-Air BB48HC-PT-S pass thru bar refrigerator makes every movement quicker. Four solid doors swing open with a 120-degree stay feature, while locks add security during slower hours. With space for (2) 1 1⁄2-barrel kegs, it helps bartenders keep popular beverages ready for service.
The Beverage-Air BB48HC-PT-S pass thru bar refrigerator maintains temperatures between 36 and 38 degrees Fahrenheit, protecting drinks from unwanted fluctuations. A balanced forced-air system moves cold evenly, while an epoxy-coated evaporator coil reinforces long-term reliability. With adaptive defrost and magnetic gaskets sealing each door, operators can trust that chilled performance continues through the busiest shifts.
- 15.14-cu.-ft. interior capacity
- (2) 1 1⁄2-barrel kegs
- Pass-thru design
- 2 sections
- 4 swinging solid doors, self-closing with locks and 120-degree stay-open feature
- 4 epoxy-coated wire shelves
- Galvanized steel interior with stainless steel floor
- 1-in. stainless steel top
- Stainless steel exterior finish
- Magnetic snap-in door gaskets
- LED interior lighting
- Frame base construction
- Packaged product storage only
- ADA-compliant height
- Self-contained, right-mounted compressor
- R290 hydrocarbon refrigerant
- Adaptive defrost
- Epoxy-coated evaporator coil
- Balanced forced-air refrigeration system
- 1,942 BTU/Hr capacity
- 2,913 BTU/Hr heat rejection
- Temperature range: 36-38 degrees F
- Interior: 36 1⁄2 in. W x 23 1⁄2 in. D x 30 1⁄2 in. H
- Overall: 48 in. W x 34 1⁄8 in. D x 34 in. H
- 3 A, 1⁄4 HP
- 115 V/60 Hz/1 ph, NEMA 5-15P plug
*Nominal cubic footage measurements sometimes provided by refrigeration manufacturers may not indicate actual usable space. If you require a specific capacity, please call one of our customer care representatives to ensure the unit you order meets your needs.
*Image may not depict product color, inclusions or accessories.
*Free shipping on Beverage-Air BB48HC-PT-S within the 48 contiguous states.
From The Manufacturer
Refrigerated Pass-Thru Back Bar Refrigerator, two-section, 48"W x 34-1/8"D x 34"H, 15.139 cu. ft., (4) solid doors with locks, (4) epoxy coated steel shelves, (2) 1/2 barrel keg, LED interior lighting, 1" stainless steel top, galvanized steel interior with stainless steel floor, stainless steel exterior, right-mounted self-contained refrigeration, R290 Hydrocarbon refrigerant, 1/4 HP, 3 amps, 115v/60/1-ph, NEMA 5-15P, cULus, UL EPH Classified
Watch a video about this product
Beverage-Air BB48HC-PT-S Specifications
| Spec Attribute | Spec Value |
|---|---|
| Manufacturer | Beverage-Air |
| Base | Frame |
| Color | Silver |
| Compressor Location | Right |
| Cubic Feet | 15.14 |
| Depth (in) | 34.13 |
| Door Design | Swing |
| Door Type | Solid |
| Height (in) | 34 |
| Hertz | 60 |
| NEMA | 5-15P |
| No. of Doors | 4 |
| Number of Levels | 3 |
| Phase | 1 |
| Product | Back Bar Coolers |
| Product Type | Commercial Refrigeration |
| Rating | Better |
| Refrigerant | R290 (Hydrocarbon) |
| Sections | 2 |
| Special Features | Door Locks |
| Special Features | LED Lighting |
| Special Features | Pass Thru |
| Thermometer Type | Digital |
| Voltage | 115 |
| Warranty | 7-year Limited Parts & Labor; 7-year Compressor Parts |
| Width (in) | 48 |
| Weight | 326.70 |
