Thermaco W-500-IS-X 108 2/5 lb Big Dipper® Pro Grease Trap w/ 50 GPM Capacity, Polyethylene/Stainless Steel
Typically ships in 2 - 3 weeks
Retail Price: $4,790.00
$4,420.89 /Each
Thermaco W-500-IS-X Description
Designed to manage up to 108 2⁄5 pounds of grease at a flow rate of 50 gallons per minute, the Thermaco W-500-IS-X Big Dipper® Pro grease trap supports reliable separation in high-volume commercial kitchens. A digital control system enables programmable operation, while a 3-inch inlet and outlet and 1-inch vessel vent help maintain consistent flow and ventilation. The system features a self-regulating electric immersion heater with thermostatic control to maintain optimal temperature during grease collection and separation.
The Thermaco W-500-IS-X grease trap includes a rotationally molded polyethylene interior housed in a 304 stainless steel exterior for corrosion resistance and structural longevity. Stainless steel quick-release lid clamps provide easy access for service, and the internal strainer basket enhances durability and simplifies removal. An integral gas trap reduces odors, and a field-reversible motor assembly and grease/oil sump outlet support flexible installation in varied layouts.
- Big Dipper Pro series
- 108 2⁄5-lb. grease capacity
- Rated for 50-GPM flow
- 304 stainless steel exterior
- Rotationally molded polyethylene interior
- Internal polymer/stainless steel strainer basket
- Quick-release stainless steel lid clamps
- Field-reversible motor assembly and grease/oil sump outlet
- Self-regulating immersion heater with thermostatic control
- Digital programmable operation
- 1-in. vessel vent
- 3-in. inlet and outlet connections
- Silver
- Smart skimming only skims when grease is ready
- Smart mainetenance streamlines upkeep
- Smart control via Big Dipper Connect app
- 38 in. L x 24 3⁄10 in. W x 21 6⁄7 in. H
- 10.2 A, 1,173 W
- 115 V/50⁄60 Hz/1 ph, cord with NEMA 5-15P plug
*Image may not depict product color, inclusions or accessories.
*Free shipping on Thermaco W-500-IS-X within the 48 contiguous states.
From The Manufacturer
Big Dipper® Pro Grease Trap, automatic, 108.4 lbs. grease capacity, 50 gallons per minute, 3" inlet/outlet size, 1" vessel vent, self-regulating electric immersion heater with thermostatic control, integral gas trap, digital control for programmable operation, field reversible motor assembly and grease/oil sump outlet, quick release stainless steel lid clamps, internal polymer/stainless steel strainer basket, rotationally molded polyethylene interior, 304 stainless steel exterior, 1173 watts, 10.2 amps, 115v/50-60hz/1-ph, cCSAus, PDI Certified
Watch a video about this product
Thermaco W-500-IS-X Specifications
| Spec Attribute | Spec Value |
|---|---|
| Manufacturer | Thermaco |
| Also Known As | W-500-IS |
| Capacity (lbs) | 108.4 |
| Color | Silver |
| Flow Rate | 50 gpm |
| Height (in) | 21.86 |
| Hertz | 50/60 |
| Length (in) | 38 |
| Material | Polyethylene/Stainless Steel |
| NEMA | 5-15P |
| Phase | 1 |
| Product | Grease Traps |
| Product Type | Cleaning & Janitorial |
| Series | Big Dipper® Pro |
| Type | Automatic Grease Traps |
| Voltage | 115 |
| Warranty | Limited Lifetime; 3-year Electrical Components |
| Width (in) | 24.3 |
| Weight | 130.00 |
