Delfield 8172-EFP 72" Drop-In Refrigerator w/ (5) Pan Capacity - Cold Wall Cooled, 115v
Typically ships in 2 - 3 weeks
$8,080.00 /Each
Login or call for details!
Ship times may vary due to supply chain constraints. Please contact our Sales Team if you need this item in a specified time frame.
White Glove Delivery
Contact your sales rep for availability
Similar Products in Stock Now
Delfield 8172-EFP Description
To maintain temperatures between 33 and 41 degrees Fahrenheit, the Delfield 8172-EFP LiquiTec® drop-in refrigerator uses a LiquiTec self-contained eutectic fluid refrigerated system. Operators can adjust these levels using precise electronic controls, and the unit's sides and bottom are insulated with high-density polyurethane to preserve low temperatures. To minimize its environmental impact, this food well operates with R290 refrigerant—a type of eco-friendly hydrocarbon.
For durability to withstand rigorous use, the Delfield 8172-EFP drop-in cold food unit features a galvanized steel exterior. Its top, inner liner, and louver are constructed of stainless steel to provide additional strength and corrosion resistance. This unit accommodates five full-size pans with depths of 4 or 6 inches. Overall, this unit measures 727/16 inches wide by 26 inches deep by 246/25 inches high, and it requires a 711/2-inch by 25-inch counter cutout.
Product Details
- 12-in. x 20-in. stainless steel wells accommodate 5 pans measuring 4 or 6 in. deep
- Drop-in model for installation flush with countertop
- Requires 711/2-in. x 25-in. counter cutout
- Electronic temperature control
- Temperature holding range: 33-41 degrees F
- Sides and bottom are insulated with high-density polyurethane
- Corrosion-resistant stainless steel top, inner liner, and louver
- LiquiTec self-contained eutectic fluid refrigerated system
- Exterior housing made of galvanized steel
- 1⁄2-in. stainless steel drains with manifold
- Eco-friendly R290 hydrocarbon refrigerant
Product Features
Dimensions & Utilities
- 727/16 in. W x 26 in. D x 246/25 in. H
- 4.8 A, 1⁄3 HP
- 115 V/60 Hz/1 ph, 8-ft. cord with NEMA 5-15P plug
*Free shipping on Delfield 8172-EFP within the 48 contiguous states.
From The Manufacturer
LiquiTec® Drop-In Cool Food Unit, 5-pan size, 4" or 6" deep pans flush with counter top, insulated pan, stainless steel inner liner & top, galvanized outer liner, self-contained Eutectic fluid refrigerated system, R290 Hydrocarbon refrigerant, 1/3 hp, (71-1/2" x 25" cutout required), cUL, UL, NSF
*Image may not depict product color, inclusions or accessories.
Delfield 8172-EFP Specifications
| Spec Attribute | Spec Value |
|---|---|
| Manufacturer | Delfield |
| Access | Top |
| Also Known As | 8172-EF |
| Height (in) | 23.25 |
| Hertz | 60 |
| Length (in) | 72 |
| Pan Capacity | 5 |
| Phase | 1 |
| Product | Cold Wells |
| Product Type | Food Bars & Buffets |
| Refrigeration Type | Refrigerated |
| Series | LiquiTec® |
| Type | Cold Wall |
| Voltage | 115 |
| Warranty | 1-year Parts & Labor |
| Width (in) | 26 |
| Weight | 295.00 |
Important Prop 65 information for California residents.
- Delfield 8172EF
