Master-bilt DD-88 90.75" Stand Alone Ice Cream Freezer w/ 16-Tub Capacity & 12-Tub Storage, 115v

KaTom #: 050-DD88 • MPN: DD-88

Extended Lead Time (14+ days)

(0 reviews)Write a Review
Retail Price: $5,364.81

Master-bilt DD-88 Description

The Master-Bilt DD-88 ice cream dipping and display cabinet is built with rugged 24-gauge textured steel interior and exterior, both of which are painted white to create an attractive display and a scratch-resistant, easy-to-clean finish. Fluorescent lighting illuminates the ice cream on display, while the tempered glass viewing windows allow customers to easily see their choices. This unit holds 16 standard-sized, 3-gallon ice cream tubs on its display rack, with room for an additional 12 in the concealed storage base. Staff has easy access to products through hinged, high-tensile acrylic lids, which are fitted with easy-to-lift, full-length handles. Products can be passed to the customers over the stainless steel serving deck, which is easy to clean.

This Master-Bilt DD-88 ice cream dipping and display cabinet is insulated with 214 inches of foamed in place urethane, an environmentally-friendly substance that helps the cabinet maintain cold temperatures and also makes the cabinet rigid and long-lasting. Wiper gaskets on the cabinet lids also help to prevent cold air from escaping. The 34 horsepower refrigeration system uses an industry-standard R-404A refrigerant, circulated through a low-maintenance, bare-tube condenser coil. The cold wall evaporator is designed to efficiently cool the ice cream being held. Operators have access to a temperature adjustment knob, which lets them adjust temperatures along a range of -5 to 5 degrees Fahrenheit.

Product Details

  • Heavy-duty acrylic lids are equipped with full-length handles for easy opening and closing
  • Lids are equipped with wiper gaskets to help seal in cold air
  • Leveling legs allow equipment to be properly installed on uneven floors
  • Interior is illuminated with fluorescent lighting to make ice cream more visible for customers
  • Power to lights and compressor can be controlled independently with separate on/off switches for each
  • Cans are supported on epoxy coated racks for organization and cleanliness
  • Air is taken in and discharged from the rear of the equipment so it can be installed flush against walls or equipment on both sides
  • Interior drain's outlet can be connected to a garden hose so the unit can be thoroughly cleaned
  • Uses industry-standard R404A refrigerant, circulated through a cold wall evaporator to consistently cool dense tubs of ice cream
  • Bare tube condenser coil's simple design requires little maintenance
  • -5 to 5 degree F temperature range can be adjusted with control knob
  • 115 V/60 Hz/1-ph, 11.5 A, 34 HP, 9-ft. cord with a NEMA 5-15P plug
  • Overall Dimensions: 9034 in. W x 2734 in. D x 50 in. H
  • cULus listed; NSF certified

Construction

  • Interior and exterior are both made with 24-gauge textured steel and painted white
  • Viewing window is made of rugged tempered glass, allowing customers to easily see inside
  • Stainless steel superstructure provides structural integrity and corrosion resistance
  • Cabinet is insulated with foamed in place urethane, which also provides structural integrity
  • Stainless steel serving deck allows items to be served to customers while being easily cleaned

Ice Cream Dipping/Display Cabinet, (16) 3 gallon can display, (12) 3 gallon storage, painted textured galvanized steel interior and exterior, 50" high stainless steel serving deck, glass view windows, fluorescent light with switch, temperature range 5° to -5° F, 3/4 hp, 115v/60/1-ph, 11.5 amps, 9' cord, NEMA 5-15P, UL, cUL, NSF

*The warranty will not be honored for residential or non-commercial use of any Commercial Equipment.

Master-bilt DD-88 Specifications

PDF Spec Sheet
Manufacturer Master-bilt
Containers Tubs
Depth (in) 28
Design Straight
Exterior Finish White
Refrigeration Type Cold Wall
Specialty Options Lighted
Specialty Options Cold Storage
Type Stand Alone
Voltage 115/60/1
Warranty 2 years part & labor/5 years compressor
Width (in) 91
Capacity (3 Gal Cans) 28
Weight 600.00
Master-bilt DD-88 Certifications
  • UL
  • NSF
