Ice-O-Matic CIM0530HA90 30 1/4" Elevation Series™ Half Cube Ice Machine Head - 525 lb/24 hr, Air Cooled, 115v/1ph
QUICK SHIP: Typically ships in 1 - 3 Business Days
$4,046.00 /Each
Selected Ice Type: Half Cube
Ice-O-Matic CIM0530HA90 Description
The Ice-O-Matic CIM0530HA90 Elevation™ modular cube ice maker can produce 525 pounds of half-cube ice in a 24-hour period when operating in ambient air temperatures of 70 degrees Fahrenheit. The dual exhaust system expels air from the side or top of the unit, providing operators with a variety of installation options. The Universal Smart Harness™ control board simplifies installation and service with better access, digital diagnostics, and a common configuration.
The plastic food zone has no crevices so it can be thoroughly wiped clean, and bacteria growth in this area is slowed by built-in Agion® antimicrobial protection. When the Ice-O-Matic CIM0530HA90 Elevation modular cube ice maker requires cleaning, the LED status display alerts the operator; one-touch controls make it easy for employees to sanitize and descale the unit.
Note: This unit must be paired with an ice maker bin or ice dispenser.
- Dispenses 525 lbs. of ice in 24 hrs. when at 70 degrees F, 390 lbs. when at 90 degrees F
- Produces half-cube ice that measures 3⁄8 in. x 7⁄8 in. x 7⁄8 in.
- Condenser is air cooled and self-contained
- Dual exhaust expels hot air from the side or top for installation flexibility
- Easy to install and maintain with universal components, digital diagnostics, and common configuration provided by Universal Smart Harness control board
- Recyclable plastic parts are BPA free
- R290 refrigerant
- 115 V/60 Hz/1 ph, 17.8 A, 5.87 kW, 6252 BTU
- Overall Dimensions: 30 1⁄4 in. W x 24 1⁄4 in. D x 21 1⁄4 in. H
- LED status display indicates when cleaning is required
- Descaling and sanitizing are easy with one-touch controls
- Plastic food zone can be wiped down since it lacks crevices
- Dishwasher-safe parts are easy to remove for cleaning
- Bacteria growth is slowed by the Agion antimicrobial protection
*Image may not depict product color, inclusions or accessories.
*Free shipping on Ice-O-Matic CIM0530HA90 within the 48 contiguous states.
From The Manufacturer
Elevation Series™ Modular Cube Ice Maker in R290, air-cooled, self-contained condenser, top air discharge, 30" W, approximately 525 lb production/24 hours at 70°/50° (400 lb at 90°/70°), half-size cubes, LED status display, one touch sanitize/descaling controls, dishwasher safe food zone components, cULus, NSF, CE, ENERGY STAR®
Watch a video about this product
Ice-O-Matic CIM0530HA90 Specifications
| Spec Attribute | Spec Value |
|---|---|
| Manufacturer | Ice-O-Matic |
| 24 Hr. Production (lb) | 525 |
| Also Known As | CIM0530HA |
| Compressor Type | Air Cooled |
| Depth (in) | 24.25 |
| Height (in) | 21.25 |
| Ice Type | Half Cube |
| Phase | 1 |
| Product | Ice Machine Heads |
| Product Type | Ice Makers & Bins |
| Rating | Better |
| Refrigerant | R290 (Hydrocarbon) |
| Series | Elevation Series™ |
| Suggested Use | Commercial |
| Voltage | 115 |
| Warranty | 3-year Parts & Labor; 5-year Evaporator & Compressor Parts |
| Water Inlet (in) | 0.38 |
| Width (in) | 30.25 |
| Weight | 160.00 |
